MAZAK INTEGREX 200 IVS CNC MULTI-TASKING TURNING CENTER

MAZAK INTEGREX 200 IVS CNC MULTI-TASKING TURNING CENTER

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
INTEGREX 200 IVS
Year:
2010
Stock #:
4639
Status:
For Sale

Description

THIS 2010 INTEGREX 200S HAS A MATRIX CONTROL, 213 PSI COOLANT THRU, 8" 3 JAW HYDRAULIC CHUCKS - BOTH SPINDLES.

Maximum Swing26.5"673.1 mm
Max Turning Diameter26"660.4 mm
Main Spindle Bore/Max Bar Capacity2.99/ 2.42.99/ 2.4
Tail Stock/Sub SpindleSub SpindleSub Spindle
Maximum Cutting Length41.14"1,045 mm
X-Axis Travel (X1, X2, X3)22.822.8
Z-Axis Travel (Z1, Z2, Z3)41.1441.14
Y-Axis Travel (Y1, Y2, Y3)6.336.33
C-Axis Indexing (1, 2).0001.0001
W-Axis Travel Sub Spindle41.1 in
Main Spindle Chuck Size8"203.2 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter2"50.8 mm
Main Spindle Maximum Bar Work2.4"60.96 mm
Main Spindle Speed-4 RPM-4 RPM
Main Spindle Horsepower (CONT. /30 MINS)3030
Sub Spindle/2nd Spindle Chuck Size88
Sub Spindle/2nd Spindle Bore Size2.99/ 2.42.99/ 2.4
Sub Spindle/2nd Spindle Chuck TypeHydraulicHydraulic
Sub Spindle/2nd Spindle Speed5,000 RPM5,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)3030
ATC Magazine Capacity40 ATC40 ATC
Turret Rotary Tool Spindle Speed 1, 21200012000
Turret Rotary Tool Horse Power 1, 22020
B-Axis Travel225 DEGREES225 DEGREES
B-Axis Head Indexing0°0.0001 deg
B Axis Rotary Tool Spindle Speed12,000 RPM12000 rpm
B-Axis Rotary Tool Spindle Horsepower20 hp
Chip ConveyorYesYes
Milling Spindle Synchronous TappingYesYes
Tool Eye Automatic Front SpindleYesYes
Tool Eye Automatic Second SpindleYesYes
Tool Eye Measurement Upper TurretYesYes
Tool Eye Measurement Lower TurretYesYes
Coolant Thru Milling HeadYesYes
High Pressure Coolant System (PSI)213213
ControlCNC (MAZATROL MATRIX)CNC (MAZATROL MATRIX)

SPECIFICATIONS:
MAX. SWING                    26.5"
MAXIMUM CUTTING LENGTH        41.14"
MAX MACHINING DIA             26"
AXIS TRAVEL X - AXIS          22.8"
AXIS TRAVEL Z - AXIS          41.14"
AXIS TRAVEL Y - AXIS          6.33"
AXIS TRAVEL B - AXIS          225 DEGREES
AXIS TRAVEL C - AXIS          .0001 INCREMENTS
AXIS TRAVEL W - AXIS .001 INCREMENTS
      (SECOND SPINDLE)        41.1"
SPINDLE BORE                  2.99"
MAX BAR CAPACITY              2.4"
SPINDLE NOSE                  A2-6
SPINDLE SPEEDS                5000 RPM
MAIN SPINDLE HORSEPOWER       30 HP AC
SECOND SPINDLE HORSEPOWER     30 HP AC
SECOND SPINDLE RPM            5000
SECOND SPINDLE INDEXING       .0001 INCREMENTS
ROTARY TOOL SPINDLE SPEED     12,000 RPM
ROTARY TOOL MOTOR             20 HP
MAX TOOL DIA. (ADJ.)          3.54"/4.92"
MAX TOOL LENGTH               11.8"
TOOL MAGAZINE CAPACITY        40 ATC
B-AXIS / COUPLING             5 DEGREE
RAPID TRAVERSE RATES C - AXIS 555 RPM
MAXIMUM TOOL WEIGHT           22 LBS.
Z - AXIS THRUST               3124 FT/LBS.

MAZATROL MATRIX CONTROL
213 PSI THRU UPPER TURRET
600 MACRO VARIABLES
8" 3-JAW HYDRAULIC THRU HOLE CHUCKS BOTH SPINDLES
AUTO CHUCK JAW OPEN/CLOSE
BACKGROUND TOOL PATH CHECK
B-AXIS .0001 DEGREE N/A CONTOURING
B-AXIS INDEX 5 DEGREE COUPLING CLAMP
C-AXIS .0001 DEGREE 1ST AND 2ND SPINDLE
COOLANT THRU MILLING HEAD
EIA/ISO PROGRAMMING
ENHANCED MAZATROL Y-AXIS FACE 1 & 2
HYDRAULIC PRESSURE INTERLOCK
MILLING SPINDLE MULTI-ORIENTATION
MILLING SPINDLE SYNCHRONOUS TAPPING
TOOL EYE AUTOMATIC FRONT AND SECOND SPINDLE
TOOL EYE MEASUREMENT FOR UPPER AND LOWER TURRET
TOOL LIFE MONITORING
USER MACRO
CHIP CONVEYOR (SIDE)
ALL AVAILABLE TOOLING
ALL AVAILBLE MANUALS
