MAZAK QTN 250-II MY W/ GL-100F GANTRY LOADER
Have one to sell?
ConditionUsed
1 available
THIS QTN 250MY HAS A GL 100 ROBOT w/ 6 PALLET PITCH FEED, MATRIX CONTROL, 213 PSI COOLANT THRU AND TAILSTOCK.
SPECIFICATIONS:
MAXIMUM SWING / SWING OVER CROSS SLIDE 26.5" / 16.04"
MAXIMUM TURNING DIAMETER / LENGTH 14.75" / 19.85"
SPINDLE SPEEDS 4,000 RPM
SPINDLE BORE / BAR CAP / SPINDLE NOSE 3.46" / 3" / A2-8
MOTOR (30 MIN / CONTINUOUS) 35 / 30 HP
TURRET: NUMBER OF POSITIONS 12 POSITIONS - ALL LIVE
TRAVELS: X-AXIS TRAVEL 9"
Z-AXIS TRAVEL 22.75"
Y-AXIS TRAVEL +/- 2"
C-AXIS INDEXING 360,000°
ROTARY TOOLS: ROTARY TOOL SPEED 4,500 RPM
ROTARY TOOL MOTOR 7.5 HP
TAILSTOCK: STROKE OF BODY / QUILL 20" / 4"
QUILL DIAMETER / TAPER 3.9" / # 4 MT
RAPIDS: RAPID TRAVERSE (X/ Z & B/ Y) 1181 / 826 IPM
DIMENSIONS: FLOOR SPACE 106.8 x 73.2" X 75"
WEIGHT (APPROX) 12,000 LBS
MAZATROL MATRIX CONTROL
GL 100F ROBOT w/6 PALLET PITCH FEED
CONVERTER SYSTEM/ D3 HAND/ JAW AB
X AXIS SCALE
213 PSI HIGH-POWER COOLANT
CHIP CONVEYOR SIDE 500U (20")
ALL AVAILABLE TOOLING AND MANUALS
THIS QTN 250MY HAS A GL 100 ROBOT w/ 6 PALLET PITCH FEED, MATRIX CONTROL, 213 PSI COOLANT THRU AND TAILSTOCK.
Imperial
| Maximum Swing | 26.5" |
| Max Turning Diameter | 14.75" |
| Main Spindle Bore/Max Bar Capacity | 3.46" / 3" |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Swing Over Cross Slide | 16.4" |
| Maximum Cutting Length | 19.85" |
| X-Axis Travel (X1, X2, X3) | 9 |
| Z-Axis Travel (Z1, Z2, Z3) | 22.75 |
| Y-Axis Travel (Y1, Y2, Y3) | +/- 2" |
| C-Axis Indexing (1, 2) | 360,000° |
| Main Spindle Chuck Size | 10" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 3.46" |
| Main Spindle Maximum Bar Work | 3" |
| Main Spindle Speed | 4,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 35/ 30 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 4500 |
| Turret Rotary Tool Horse Power 1, 2 | 7.0 |
| Chip Conveyor | Yes |
| High Pressure Coolant System (PSI) | 213 |
| Gantry System | Yes |
| Control | CNC (MAZATROL MATRIX) |
| Dimensions | 106.8 x 73.2" X 75" |
| Weight | 12,000 LBS |
SPECIFICATIONS:
MAXIMUM SWING / SWING OVER CROSS SLIDE 26.5" / 16.04"
MAXIMUM TURNING DIAMETER / LENGTH 14.75" / 19.85"
SPINDLE SPEEDS 4,000 RPM
SPINDLE BORE / BAR CAP / SPINDLE NOSE 3.46" / 3" / A2-8
MOTOR (30 MIN / CONTINUOUS) 35 / 30 HP
TURRET: NUMBER OF POSITIONS 12 POSITIONS - ALL LIVE
TRAVELS: X-AXIS TRAVEL 9"
Z-AXIS TRAVEL 22.75"
Y-AXIS TRAVEL +/- 2"
C-AXIS INDEXING 360,000°
ROTARY TOOLS: ROTARY TOOL SPEED 4,500 RPM
ROTARY TOOL MOTOR 7.5 HP
TAILSTOCK: STROKE OF BODY / QUILL 20" / 4"
QUILL DIAMETER / TAPER 3.9" / # 4 MT
RAPIDS: RAPID TRAVERSE (X/ Z & B/ Y) 1181 / 826 IPM
DIMENSIONS: FLOOR SPACE 106.8 x 73.2" X 75"
WEIGHT (APPROX) 12,000 LBS
MAZATROL MATRIX CONTROL
GL 100F ROBOT w/6 PALLET PITCH FEED
CONVERTER SYSTEM/ D3 HAND/ JAW AB
X AXIS SCALE
213 PSI HIGH-POWER COOLANT
CHIP CONVEYOR SIDE 500U (20")
ALL AVAILABLE TOOLING AND MANUALS
