MAZAK QTN 250MSY MULTI AXIS LATHE

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
QTN 250MSY
Condition:
Excellent
Year:
2012
Stock #:
5903
Status:
For Sale

Description

** PENDING RELEASE DATE **
THIS 2012 QTN 250MSY HAS A MATRIX NEXUS CONTROL, AUTOMATIC PARTS CATCHER, LNS QUICK LOAD BARFEEDER, C-AXIS 0.0001 ON BOTH SPINDLES AND 213 PSI COOLANT THRU.

Maximum Swing14.75"374.65 mm
Max Turning Diameter10.87"276.1 mm
Main Spindle Bore/Max Bar Capacity3.46/ 3.03.46/ 3.0
Tail Stock/Sub SpindleSub SpindleSub Spindle
X-Axis Travel (X1, X2, X3)9.09.0
Z-Axis Travel (Z1, Z2, Z3)22.6322.63
Y-Axis Travel (Y1, Y2, Y3)+/- 2.0"+/- 2.0"
C-Axis Indexing (1, 2)0.0001/ 0.00010.0001/ 0.0001
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.46"87.884 mm
Main Spindle Maximum Bar Work3"76.2 mm
Main Spindle Speed4,000 RPM4,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)3535
Sub Spindle/2nd Spindle Chuck Size66
Sub Spindle/2nd Spindle Bore Size2.052.05
Sub Spindle/2nd Spindle Chuck TypeHydraulicHydraulic
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)1515
Number of Turrets11
Turret Tool Positions 1, 21212
Turret Rotary Tool Spindle Speed 1, 245004500
Turret Rotary Tool Horse Power 1, 27.57.5
Bar FeedYesYes
Parts CatcherYesYes
Chip ConveyorYesYes
Tool Eye Automatic Front SpindleYesYes
Tool Eye Automatic Second SpindleYesYes
High Pressure Coolant System (PSI)213213
Multi Tap TransformerYesYes
ControlCNC (MAZATROL MATRIX NEXUS)CNC (MAZATROL MATRIX NEXUS)
Dimensions115.4 X 70.1" X 72.4115.4 X 70.1" X 72.4
Weight11,464 LBS11,464 LBS

SPECIFICATIONS:
SWING OVER CARRIAGE 14.75"
MACHINING DIAMETER 10.87"
X AXIS TRAVEL 9.00"
Y AXIS TRAVEL +/-2.00"
Z AXIS TRAVEL 22.63"
TORQUE (SPINDLE) CONT: 35 HP
MAX SPEED (SPINDLE) 4000 RPM
C AXIS INDEXING 0.0001 DEG
NOSE (SPINDLE) A2-8
BORE (SPINDLE) 3.46"
BAR DIA 3.0"
CHUCK TYPE HYDRAULIC
TURRET TYPE DRUM
TURRET POSITIONS 12
POWER (SUBSPINDLE) CONT: 15 HP
TORQUE (SUBSPINDLE) 30 MIN: 58 FT/LBS
MAX SPEED (SUBSPINDLE) 6000 RPM
INDEXING (SUBSPINDLE) 0.0001 DEG
NOSE (SUBSPINDLE) A2-6
CHUCK TYPE (SUBSPINDLE) HYDRAULIC
CHUCK DIAMETER (SUBSPINDLE) 6.00"
POWER (ROTARY TOOL SPINDLE) CONT: 7.5 HP
MAX SPEED (ROTARY TOOL SPINDLE) 4500 RPM
FLOOR SPACE 115.4 X 70.1"
MACHINE HEIGHT 72.4"
WEIGHT 11464 LB

MAZATROL MATRIX NEXUS CONTROL
WINDOWS XP OPERATING SYSTEM FOR MAZAK MACHINE CONTROL.
12.1" COLOR LCD USB I/F (2-PORT) LAN PORT
USB 1/F (2-PORT)
LAN PORT
MT CONNECT PREPARATION
USER MACRO (COMMON VARIABLES: 600 PAIRS) (MXN-036MT)
MAZAK TAPPING/BORING TORNADO MXN-043MT EIA HELICAL TAP CYCL
EIA/ISO INPUT FUNCTION
(MXN-001MT)
SEQUENCE NUMBER COMPARISON STOP FUNCTION (MNX-022MT)
B)CYLINDRICAL(G07)&POLAR COORDINATE(G12) MXN-038MT
ABSOLUTE POSITIONING SYS (N/A WITH S/F)
TOOL EYE (AUTOMATIC)
Y-AXIS CONTROL
213 PSI HIGH-POWER COOLANT
AUTOMATIC PARTS CATCHER (DIA. 3" X 4.7" X 5.5 LBS)
CHIP CONVEYOR SIDE DISPOSAL (HINGE TYPE)
BARFEEDER INTERFACE KIT
BAR FEEDER LNS QUICK LOAD SERVO 80-S2
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
HYDRAULIC PRESSURE INTERLOCK
12 POSITION VDI TURRET
ROLLER GUIDE
MULTITAP TRANSFORMER
RELOCATION DEVICE
ROTARY-TOOL SPINDLE SPEED 4500 RPM
C-AXIS 0.0001 DEGREE INCR.(1ST SPINDLE)*
1ST SPINDLE MOTOR AC 26KW(35HP)
1ST SPINDLE SPEED 4000 RPM
A2-8 NOSE
(1ST SPINDLE)ROYAL PRODUCTS A2-8 ACCULENGTI S30 COLLET CHUCK
SPINDLE BORE DIA. 91mm (3.58")
KITAGAWA B-210-A8 W/ S-1877 CYL. (3.03" CAP.)
AUTO CHUCK JAWS OPEN/CLOSE (1&2 SPINDLE)
CHUCK OPEN/CLOSE CONFIRM. (1&2 SPINDLE)
2ND SPINDLE C-AXIS .0001 DEG. INCLUDING EIA INPUT FUNCTION
SECOND SPINDLE MOTOR (15HP)
SECONDSPINDLE BORE DIA. 52MM (2.05"/ A2-5 NOSE/ 6000 RPM
KITAGAWA B-206A5 W/ RNKP105-15 CLOSED CYL.
CHUCK AIR BLAST (SECOND SPI NOLE)
ROLLER GUIDE
MULTITAP TRANSFORMER
RELOCATION DEVICE
