TOSHIBA TUE 100S BORING MILL WITH LIVE SPINDLE
Must Move Immediately - Priced to Sell - VTL Vert. Live Spindle CNC
TOSHIBA TUE 100S - MUST SELL TO THE ON - GOING CONCERNS OF MAJOR SEMI CONDUCTOR FACILITYTHIS 2015 TOSHIBA TUE 100S HAS DUAL FACE CONTACT WITH COOLANT THRU THE SPINDLE, 40" HYDRAULIC CHUCK, SPINDLE CHILLER, X-AXIS LINEAR SCALE FEEDBACK FOR HIGH ACCURACY, TABLE LUBRICANT OIL COOLING UNIT, AND FANUC CONTROL AND STANDARD TOOLING PACKAGE.
THE BED IS MADE OF CAST IRON, HAVING RATIONALLY ARRANGED RIBS TO COMPLETELY SUPPORT THE TABLE. ADDITIONALLY, A THERMALLY SYMMETRICAL DESIGN AND A STANDARD EQUIPPED LUBRICANT OIL COOLING UNIT CONTRIBUTE TO MINIMIZING THERMAL DISTORTION TO REALIZE A HIGH THERMAL-RIGIDITY STRUCTURE
| Table Dia | 40" |
| Max Swing | 47.2" |
| Maximum Turning Diameter | 40" |
| Maximum Turning Height | 33.5 |
| Table Weight Capacity | 4,400 lb |
| Vertical Travel of Ram, Z-Axis | 31.4" |
| Horizontal Railhead Travel, X-Axis | -20.0 ~ 29.5 |
| Main Table Motor | AC 60/50 |
| Live Spindle Motor | AC 25/20 HP |
| Live Spindle Speed, 2-Ranges | 15 ~ 3,000 RPM |
| C-Axis Contouring | 1 DEGREE |
| Table RPM | 600 RPM |
| Automatic Tool Changer | 18 |
| Tool Shank | No. 50 |
| Control | CNC (FANUC 0i-TF) |
| Dimensions | 198x142x183 |
| Weight | 37,400 LBS |
Swing/Cut inch(mm) 47.2 (1200)
Cut Height inch(mm) 33.5 (850)
X Stroke inch(mm) -20.0 ~ 29.5 (-510 ~ 750)
Z Stroke inch(mm) 31.4 (800)
TABLE size inch(mm) 40 (1016)
Max. load lbs(kg) 4400 (2200)
Table RPM 600
Live Spindle RPM 3,000
ATC Tool Pod 18
Control FANUC 0i-TF
FANUC 0i-TD CONTROL
40" HYDRAULIC CHUCK
SPINDLE CHILLER
DUAL FACE CONTACT WITH COOLANT THRU SPINDLE
X-AXIS LINEAR SCALE FEEDBACK FOR HIGH ACCURACY
TABLE LUBRICANT OIL COOLING UNIT
THE BED IS MADE OF CAST IRON, HAVING RATIONALLY ARRANGED RIBS TO SUPPORT THE TABLE COMPLETELY. ADDITIONALLY, A THERMALLY SYMMETRICAL DESIGN AND A STANDARD EQUIPPED LUBRICANT OIL COOLING UNIT CONTRIBUTE TO MINIMIZE THERMAL DISTORTION TO REALIZE A HIGH THERMAL-RIGIDITY STRUCTURE
