2024 HYUNDAI WIA LV 8500RM

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
VTL VERT. LIVE SPINDLE CNC
Manufacturer:
HYUNDAI WIA
Model:
LV 8500RM
Condition:
Excellent
Year:
2024
Stock #:
210889
Status:
For Sale

Description

2024 HYUNDAI WIA LV 8500 CNC 3 AXIS VERTICAL TURNING LATHE WITH MILLING, features a 24" 3-jaw hydraulic chuck and Fanuc I Series CNC color control. Equipped with tool setter, chip conveyor, and ethernet function. It boasts a 60 hp main motor, A2 -15 spindle nose, 1760 RPM table speed, and 12-station turret with 15 HP BMT 75 milling spindle at 4000 RPM.

Table Dia24"609.6 mm
Maximum Swing33.5"850.9 mm
Maximum Turning Height31.431.4
Vertical Travel of Ram, Z-Axis31.5"800.1 mm
Horizontal Railhead Travel, X-Axis18.3"18.3"
Chuck size2424
Main Table Motor60 HP60 HP
Table RPM1,780 RPM1,780 RPM
Live Spindle Motor15 HP15 HP
Live Spindle Speed, 2-Ranges4000 RPM4000 RPM
C-Axis Contouring.001.001
Automatic Tool Changer1212
Rapid Traverse X/Z787787
ControlCNC (FANUC I Series)CNC (FANUC I Series)
Weight21,000 LBS21,000 LBS

SPINDLE NOSE A2 - 15

***LESS THAN 200 CUTTING HOURS ***
FANUC I SERIES CNC COLOR CONTROL
SMART GUIDE I CONVERSATIONAL PROGRAMMING
24" 3-JAW HYDRAULIC CHUCK
CHIP CONVEYOR COOLANT TANK
520 METERS 2MB PROGRAM STORAGE, 1000 RREGISTERABLE PROGRAMS
THRU SPINDLE AIR BLOW 1.5 BAR
TOOL PRE SETTER
BMT 75 SERVO TURRET
(1) O.D. ROTARY HOLDER
(1) I.D. ROTARY HOLDER
ALL BOX WAY CONSTRUCTION
USB PORT
FULL COMPLEMENT OF STATIC TOOL HOLDERS
ALL AVAILABLE MANUALS
