DOOSAN PUMA 300LC

SPECIFICATIONS:
SWING OVER BED               22.44"
SWING OVER SADDLE            14.57"
RECOM. TURNING DIAMETER`     12"
MAXIMUM TURNING DIA          15.74"
DRAW TUBE DIA.               4.06"
SPINDLE BORE                 4.53"
MAXIMUM TURNING LENGTH       50.34"
X AXIS TRAVEL                11.10"
Z AXIS TRAVEL                52.4"
SPINDLE MOTOR                (30 MIN) 30/35
SPINDLE SPEED                28 - 2800 RPM
SPINDLE NOSE                 A2-11
NUMBER OF TOOL               10
X AXIS RAPID TRAVERSE        787 IPM
Z AXIS RAPID TRAVERSE        945 IPM
TAILSTOCK QUILL DIA          MT#5 / 3.94"
TAILSTOCK QUILL TRAVEL       3.94"
SIZE                         135" X 70"
WEIGHT                       11,000 LBS OR 13,000 LBS
