DOOSAN PUMA 300LMC CNC UNIVERSAL LATHE WITH MILLING & STEADY REST

SPECIFICATIONS:
MAXIMUM SWING OVER BED      23"
SWING OVER SADDLE           17.7"
MAX. TURNING DIAMETER       15.8"
MAXIMUM TURNING LENGTH      47.8"
DISTANCE BETWEEN CENTERS    50.6"
SPINDLE BORE DIAMETER       4.53"
BAR CAPACITY                4.05"
CHUCK SIZE                  12"
SPINDLE NOSE                A2-11
SPINDLE SPEEDS              28 - 2800 RPM
GEAR RANGES                 2
SPINDLE TORQUE              884 FT-LBS
MAIN MOTOR                  35 HP
X - AXIS TRAVEL             11.1"
Z - AXIS TRAVEL             52.4"
C - AXIS INDEXING           .001 DEGREE
RAPID TRAVERSE X, Z         787/945 IPM
TURRET CONFIGURATION        12
ROTARY TOOL SPINDLE SPEED   4000 RPM
ROTARY TOOL HORSE POWER     5.4 HP
TAIL STOCK QUILL DIAMETER   3.9"
PROGRAMABLE T. S. BODY      STANDARD
TAIL STOCK QUILL TRAVEL     3.9"
MACHINE WEIGHT              14,770 LBS.
