DOOSAN PUMA 700L BIG BORE LATHE
Have one to sell?
ConditionUsed
1 available
THIS 2013 DOOSAN PUMA 700L CNC LATHE FEATURES A FANUC 32i CONTROL, TAILSTOCK AND 21" CHUCK WITH 7" BORE AND SCHUNK STEADY REST
SPECIFICATIONS:
MAXIMUM SWING OVER BED 40.6"
MAXIMUM TURNING DIAMETER SHAFT WORK 31.5"
MAXIMUM TURNING DIAMETER CHUCKING 35.4"
DISTANCE BETWEEN CENTERS 125.9"
SPINDLE NOSE A1 - 15"
SPINDLE BORE DIAMETER 7.12"
SPINDLE SPEEDS 1,500 RPM
GEAR RANGES 3
SPINDLE TORQUE 3,998 FT-LBS
MAIN MOTOR 60 HP
X - AXIS TRAVEL 18.5"
Z - AXIS TRAVEL 127.36"
RAPID TRAVERSE X, Z 472, 394 IPM
TURRET CONFIGURATION 12
TAILSTOCK SPINDLE TAPER MT # 6
MAXIMUM TAILSTOCK QUILL THRUST 9,440 LBS.
PROGRAMABLE T. S. BODY STANDARD
TAILSTOCK TRAVEL 101.98"
MACHINE WEIGHT 48,000 LBS.
FANUC 32I CONTROL WITH MANUAL GUIDE I
FULLY PROGRAMABLE BODY AND QUILL TAILSTOCK
CHIP CONVEYOR
FULL BRACKETING FOR STEADY REST
SCHUNK THL 510 HYDRAULIC STEADY REST
21" 3-JAW HYDRAULIC SYSTEM
ALL AVAILABLE MANUALS
ALL AVAILABLE TOOL HOLDERS
THIS 2013 DOOSAN PUMA 700L CNC LATHE FEATURES A FANUC 32i CONTROL, TAILSTOCK AND 21" CHUCK WITH 7" BORE AND SCHUNK STEADY REST
Imperial
| Max. Swing | 40.6" |
| Max Turning Diameter | 35.4" |
| Spindle Bore/Max Bar Capacity | 7.12"/ 6.46" |
| Z Travel | 127.36" |
| X Travel | 18.5" |
| Machining Length | 126" |
| Chuck Size | 21" |
| Chuck Type | Hydraullic |
| Spindle Motor | 60 hp |
| Spindle Speeds (RPM) | 1500 |
| Spindle Bore/Bar Capacity | 7.12 in |
| Max. Bar Capacity | 6.46" |
| Turret Tool Positions | 12 |
| Tailstock | Yes |
| Chip Conveyor | Yes |
| Steady Rest | Yes |
| Control | CNC (FANUC 32I CONTROL WITH MANUAL GUIDE I) |
| Weight | 48,000 LBS |
SPECIFICATIONS:
MAXIMUM SWING OVER BED 40.6"
MAXIMUM TURNING DIAMETER SHAFT WORK 31.5"
MAXIMUM TURNING DIAMETER CHUCKING 35.4"
DISTANCE BETWEEN CENTERS 125.9"
SPINDLE NOSE A1 - 15"
SPINDLE BORE DIAMETER 7.12"
SPINDLE SPEEDS 1,500 RPM
GEAR RANGES 3
SPINDLE TORQUE 3,998 FT-LBS
MAIN MOTOR 60 HP
X - AXIS TRAVEL 18.5"
Z - AXIS TRAVEL 127.36"
RAPID TRAVERSE X, Z 472, 394 IPM
TURRET CONFIGURATION 12
TAILSTOCK SPINDLE TAPER MT # 6
MAXIMUM TAILSTOCK QUILL THRUST 9,440 LBS.
PROGRAMABLE T. S. BODY STANDARD
TAILSTOCK TRAVEL 101.98"
MACHINE WEIGHT 48,000 LBS.
FANUC 32I CONTROL WITH MANUAL GUIDE I
FULLY PROGRAMABLE BODY AND QUILL TAILSTOCK
CHIP CONVEYOR
FULL BRACKETING FOR STEADY REST
SCHUNK THL 510 HYDRAULIC STEADY REST
21" 3-JAW HYDRAULIC SYSTEM
ALL AVAILABLE MANUALS
ALL AVAILABLE TOOL HOLDERS
