HAAS ST 40L-BB
Have one to sell?
ConditionUsed
1 available
THIS HAAS ST 40LBB HAS 80" CENTERS, 20" CHUCK WITH A 7" BORE, PROGRAMMABLE TAILSTOCK, UPGRADED 55 HP SINDLE AND A STEADY REST FOR BIG PARTS.
SPECIFICATIONS:
SWING OVER FRONT APRON 34.5"
SWING OVER CROSS SLIDE 25.5"
SWING OVER TAILSTOCK 25.5"
CHUCK SIZE 20" 3 JAW"
MAX CUTTING DIAMETER 25.5"
MAX CUTTING LENGTH 80"
X AXIS TRAVELS 17"
Z AXIS TRAVELS 80"
RAPIDS ON X 710 IN/MIN
RAPIDS ON Z 320 IN/MIN
MAX THRUST X 5500 LB
MAX THRUST Z 5500 LB
SPINDLE (BIG BORE OPTION)
MAX RATING 55 HP
MAX SPEED 1400 RPM
SPINDLE NOSE A2-11
SPINDLE BORE 7.0"
TURRET NUMBER OF TOOLS 12 STATIONS
BORING BAR REAR CLEARANCE
(FROM BACK OF TURRET ) 4.37"
AIR REQUIRED 4 SCFM, 100 PSI
COOLANT CAPACITY 120 GAL
MACHINE WEIGHT 30000 LB
HAAS CNC CONTROL
IPS HAAS INTUITIVE PROGRAMMING SYSTEM
2-SPEED GEARBOX
PROGRAMMABLE HYDRAULIC TAILSTOCK
RIP-103 FULL WRAP STEADY REST FOR CNC LATHE CAPACITY 1" - 12.00"
HPC HIGH-PRESSURE COOLANT, 300 PSI (21 BAR)
HIL HIGH-INTENSITY LIGHTING
DUAL HALOGEN EXTERNAL LIGHTS
USB PORT AND RIGID TAPPING
ATP AUTOMATIC TOOL PRESETTER SYSTEM
LCC5 CHIP CONVEYOR, BELT TYPE
**EXTRA PERFORMANCE OPTION FOR ST-40, INCLUDING 55HP SPINDLE MOTOR & 12HP
Z-AXIS SERVO MOTOR
THIS HAAS ST 40LBB HAS 80" CENTERS, 20" CHUCK WITH A 7" BORE, PROGRAMMABLE TAILSTOCK, UPGRADED 55 HP SINDLE AND A STEADY REST FOR BIG PARTS.
Imperial
| Max. Swing | 34.5" |
| Max Turning Diameter | 25.5" |
| Spindle Bore/Max Bar Capacity | 7.0" |
| Z Travel | 80" |
| X Travel | 17" |
| Machining Length | 80" |
| Chuck Size | 20" |
| Chuck Type | Hydraullic |
| Spindle Motor | 55 hp |
| Spindle Speeds (RPM) | 1400 |
| Spindle Bore/Bar Capacity | 7 in |
| Max. Bar Capacity | 7" |
| Turret Tool Positions | 12 |
| Tailstock | Yes |
| High Pressure Coolant System | HPC HIGH-PRESSURE COOLANT, 300 PSI (21 BAR) |
| Chip Conveyor | Yes |
| Steady Rest | Yes |
| Control | CNC (HAAS) |
| Weight | 30,000 LBS |
SPECIFICATIONS:
SWING OVER FRONT APRON 34.5"
SWING OVER CROSS SLIDE 25.5"
SWING OVER TAILSTOCK 25.5"
CHUCK SIZE 20" 3 JAW"
MAX CUTTING DIAMETER 25.5"
MAX CUTTING LENGTH 80"
X AXIS TRAVELS 17"
Z AXIS TRAVELS 80"
RAPIDS ON X 710 IN/MIN
RAPIDS ON Z 320 IN/MIN
MAX THRUST X 5500 LB
MAX THRUST Z 5500 LB
SPINDLE (BIG BORE OPTION)
MAX RATING 55 HP
MAX SPEED 1400 RPM
SPINDLE NOSE A2-11
SPINDLE BORE 7.0"
TURRET NUMBER OF TOOLS 12 STATIONS
BORING BAR REAR CLEARANCE
(FROM BACK OF TURRET ) 4.37"
AIR REQUIRED 4 SCFM, 100 PSI
COOLANT CAPACITY 120 GAL
MACHINE WEIGHT 30000 LB
HAAS CNC CONTROL
IPS HAAS INTUITIVE PROGRAMMING SYSTEM
2-SPEED GEARBOX
PROGRAMMABLE HYDRAULIC TAILSTOCK
RIP-103 FULL WRAP STEADY REST FOR CNC LATHE CAPACITY 1" - 12.00"
HPC HIGH-PRESSURE COOLANT, 300 PSI (21 BAR)
HIL HIGH-INTENSITY LIGHTING
DUAL HALOGEN EXTERNAL LIGHTS
USB PORT AND RIGID TAPPING
ATP AUTOMATIC TOOL PRESETTER SYSTEM
LCC5 CHIP CONVEYOR, BELT TYPE
**EXTRA PERFORMANCE OPTION FOR ST-40, INCLUDING 55HP SPINDLE MOTOR & 12HP
Z-AXIS SERVO MOTOR
