HAAS TL-3B BIG BORE FLATBED
Have one to sell?
ConditionUsed
1 available
THIS HAAS TL 3B FLATBED HAS A 8.5" BORE, 60" CENTERS, DUAL 25" BISON CHUCKS WITH A 650 RPM SPINDLE AND HAAS INTUITIVE PROGRAMMING SYSTEM.
SPECIFICATIONS
SWING OVER FRONT APRON 30
OVER CROSS SLIDE 18.5
CHUCK SIZE 25 (DUAL CHUCKS)
BETWEEN CENTERS 60
MAX. CUTTING DIAMETER 30
MAX. CUTTING LENGTH 60
MAX. RPM 650
HP (KW) PEAK 30 HP
SPINDLE NOSE A2-15 (FRONT & REAR)
SPINDLE BORE 8.5
TRAVELS & FEEDRATES:
X AXIS 16
Z AXIS 60
X-AXIS MAX. THRUST 3096 LB.
Z-AXIS MAX. THRUST 3-86 LB.
RAPIDS ON X 75 IN/MIN
RAPIDS ON Z 150 IN/MIN
WEIGHT 9624 LBS
POWER REQUIRED 195-260 VAC/100A, 3-PHASE
HAAS CNC CONTROL
25 BISON 4-JAW MANUAL CHUCK
25 BISON 3-JAW MANUAL CHUCK
2-SPEED GEAR BOX
MANUAL TAILSTOCK
MANUAL TOOL POST KIT
COOLANT PUMP KIT
15 COLOR LCD MONITOR
USB PORT
INTUITIVE PROGRAMMING SYSTEM
1 MB MEMORY
PROFILING UPGRADE
MANUAL STEADY REST
