HWACHEON VTS 1150 VTL

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
VTL VERTICAL CNC
Manufacturer:
HWACHEON
Model:
VTS 1150 VTL
Year:
2009
Stock #:
5516
Status:
For Sale

Description

THIS HWACHEON VTS 1150 VTL HAS 40" TABLE AND A HEFTY 53" SWING. IT HAS A 500 RPM SPINDLE WITH A FANUC 0iTD CNC CONTROL.

Table Dia40"1,016 mm
Table Load Capacity17,125 lb7,767.8 kg
Swing53.15"1,350 mm
Turning Height37.4"949.96 mm
Main Motor73.5 hp
Number of Ranges22
X-Axis Travel2424
Z-Axis Travel37.4"949.96 mm
Rapid Traverse X, Z945/ 945945/ 945
Table Speed500 RPM500 RPM
Power73.5 hp54.8 kW
ControlCNC (FANUC 0i-TD)CNC (FANUC 0i-TD)
Weight52,191 LBS52,191 LBS

SPECIFICATIONS:
TABLE DIAMETER       40"
SWING DIAMETER       53.15"
TURNING HEIGHT       37.4"
SPINDLE NOSE         520 FLAT
TABLE SPEED          500 RPM
MAIN MOTOR           73.5 HP
NUMBER OF RANGES     2
X - AXIS TRAVEL      24"
Z - AXIS TRAVEL      37.4"
TURRET CONFIGURATION 12
RAPID TRAVERSE X, Z  945, 945 IPM
MACHINE WEIGHT       52,191 LBS.

FANUC OITD CNC CONTROL
40" 3 JAW HYDRAULIC CHUCK
CHIP CONVEYOR
COOLANT SYSTEM
HAND HELD MPG
MANUAL GUIDE I
TELESCOPIC GUARDS & COOLANT SHEILDS
X, & Z LINEAR FEEDBACK SCALES
