MAZAK HQR 250SYR (MSY) 34"/850

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
HQR 250SYR (MSY)
Year:
2013
Stock #:
4622
Status:
For Sale
Serial #:
246225

Description

THIS HQR 250SYR IS A TWIN SPINDLE, TWIN TURRET LATHE WITH MATRIX CONTROL, 10" CHUCK ON MAIN SPINDLE, 8" CHUCK ON 2ND SPINDLE WITH 2.5" THROUGH HOLE, LNS BLAZE AIR U36 AND LNS BARFEEDER.

Maximum Swing14.67"372.62 mm
Max Turning Diameter13.64"346.46 mm
Main Spindle Bore/Max Bar Capacity3.46/ 3.23.46/ 3.2
Tail Stock/Sub SpindleSub SpindleSub Spindle
Maximum Cutting Length33.86"860.04 mm
X-Axis Travel (X1, X2, X3)8.2, 6.668.2, 6.66
Z-Axis Travel (Z1, Z2, Z3)29.87, 32.1229.87, 32.12
Y-Axis Travel (Y1, Y2, Y3)44
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter3.46"87.884 mm
Main Spindle Maximum Bar Work3.2"81.28 mm
Main Spindle Speed4,000 RPM4,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)3636
Sub Spindle/2nd Spindle Chuck Size88
Sub Spindle/2nd Spindle Bore Size2.99/ 2.562.99/ 2.56
Sub Spindle/2nd Spindle Chuck TypeHydraulicHydraulic
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)3030
Number of Turrets22
Turret Tool Positions 1, 21212
Bar FeedYesYes
Chip ConveyorYesYes
(HQR) Max. Swing Over Upper Turret14.67 in
(HQR) Standard Chuck Dia. Main Spindle (L)10"254 mm
(HQR) Standard Chuck Dia. Second Spindle (R)8"203.2 mm
ControlCNC (MAZATROL MATRIX II)CNC (MAZATROL MATRIX II)

SPECIFICATIONS:
MAXIMUM SWING               14.67"
MAX MACHINING DIAMETER      13.64"
MAX BAR WORK                3.2"
MAX MACHINING LENGTH        33.86"
CHUCK - MAIN SPINDLE        10"
MAX SPEED                   4000 RPM
MOTOR OUTPUT/ 30 MIN        36HP/ 26kw
CHUCK - 2ND SPINDLE         8"
MAX SPEED                   6000 RPM
MOTOR OUTPUT/ 30 MIN        30 HP/ 22kw
UPPER TURRET - TOOLS        12
MAX SPEED                   6000 RPM
MOTOR OUTPUT/ 10 MIN        7.5 HP/ 6kw
LOWER TURRET - TOOLS        12
X AXIS TRAVEL               8.2"
X2 TRAVEL                   6.66"
Y AXIS TRAVEL               4"
Z AXIS TRAVEL               29.87"
Z2 AXIS TRAVEL              32.12"

MAZATROL MATRIX II CONTROL
10" CHUCK BB-210 ONLY 1ST SPINDLE
ROYAL ACCU LENGTH A8/S30 COLLET CHUCK
CHUCH AIR BLAST
AIR BLOW FOR WORK TRANSFER
TURRET AIR BLAST (UPPER LOWER)
AUTO BREAKER OF (BREAKER TRIP)
LNS QUICK LOAD SERVO 80 S2 SHORT MAG BARFEED
CHIP CONVEYOR (REAR HINGE)
ADDITIONAL COOLANT NOZZLE (1&2 SPINDLE)
LNS BLAZE AIR U36 INCLUDING (1) SPINDLE LINER (1) VACUUM LINER RISER
A SEPARATE 3-PHASE POWER DROP IS REQUIRED FOR BLAZE AIR
STANDARD VOLTAGE FOR BLAZE AIR IS 230 OR 460 VOLT (PLEASE SPECIFY)
(FURTHER INFO BLAZE UNIT) 2ND SPINDLE COMPLETE THRU HOLE PACKAGE 2.5 BAR CAPACITY
WITH LNS BLAZE AIR MODEL #U36
