MAZAK INTEGREX e420II-HST

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
INTEGREX e420II-HST
Year:
2010
Stock #:
4267
Status:
For Sale
Serial #:
221648

Description

THIS INTEGREX e-420H-ST HAS 80" CENTERS, SUB-SPINDLE, 120 TOOL ATC, 213 PSI COOLANT THRU, E-TOWER AND E-TOWER MONITOR.

Maximum Swing26.38"670.05 mm
Max Turning Diameter26.38"670.05 mm
Main Spindle Bore/Max Bar Capacity3.56"/3"3.56"/3"
Tail Stock/Sub SpindleSub SpindleSub Spindle
Maximum Swing Over Cross Slide26.38"670.05 mm
X-Axis Travel (X1, X2, X3)33.27/ 14.2533.27/ 14.25
Z-Axis Travel (Z1, Z2, Z3)82.2/ 74.5382.2/ 74.53
Y-Axis Travel (Y1, Y2, Y3)16.5416.54
C-Axis Indexing (1, 2).0001°/ .0001°.0001°/ .0001°
W-Axis Travel Sub Spindle77.28 in
Main Spindle Chuck Size10"254 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter4.08"103.63 mm
Main Spindle Maximum Bar Work3.58"90.932 mm
Main Spindle Speed6,000 RPM6,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)4040
Sub Spindle/2nd Spindle Chuck Size1010
Sub Spindle/2nd Spindle Bore Size4.084.08
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)4040
Main & Sub Spindle SynchronizationYesYes
ATC Magazine Capacity120120
B Axis Rotary Tool Spindle Speed12,000 RPM12000 rpm
B-Axis Rotary Tool Spindle Horsepower30 hp
Chip ConveyorYesYes
Milling Spindle Synchronous TappingYesYes
Tool Eye Automatic Front SpindleYesYes
Tool Eye Automatic Second SpindleYesYes
Tool Eye Measurement Upper TurretYesYes
Tool Eye Measurement Lower TurretYesYes
Coolant Thru Milling HeadYesYes
High Pressure Coolant System (PSI)213213
ControlCNC (MAZATROL MATRIX)CNC (MAZATROL MATRIX)

SPECIFICATIONS:
MAX SWING                       26.38"
MAX MACHINING DIAMETER          26.38"
SPINDLE BORE/ BAR CAPACITY      3.56"/3"
MAX MACHINING LENGTH            79.8"
MAIN SPINDLE SPEED              6000 RPM (CHUCKS 4000 RPM)
SECOND SPINDLE SPEED            6000 RPM (CHUCKS 4000 RPM)
MILLING SPINDLE                 240 DEGREES
ATC MAGAZINE CAPACITY           120 (CAPTO C6)
MAX SPEED                       12000RPM
MOTOR OUTPUT (15 MIN RATING)    30HP/22kw
X AXIS TRAVEL                   33.27"
X2 AXIS TRAVEL                  14.25"
Y AXIS TRAVEL                   16.54"
Z AXIS TRAVEL                   82.2"
Z2 AXIS TRAVEL                  74.53"
W AXIS TRAVEL                   77.28"

MAZATROL MATRIX CONTROL
10" CHUCK (B210) - 1ST SPINDLE
10" CHUCK CLOSED CYLINDER - 2ND SPINDLE
213 PSI COOLANT THRU
WORK MEASURING SYSTEM RMP 600 (PROBE)
1ST SPINDLE C-AXIS 0.0001
2ND SPINDLE C-AXIS 0.0001 CONTOURING
LOWER TURRET MILLING FUNCTION (6000 RPM)
CHUCK AIR BLAST (1ST & 2ND SPINDLE)
CONSEP CHIP CONVEYOR
ALL AVAILABLE TOOLING AND MANUALS

CONTROL OPTIONS
EIA
SPIRAL
EIA 3D COMP
ROTATION
GEOMETRIC
SCALING
EXT DATA I/O
HOB MACHINING
SHAPE COMP
THREAD
TILTED WORKING PLANE
SP/ROT. PARA. ADJUST
5 AXIS TOOL COMP
AUTO PECKING
TOOL CENTER POINT CONTROL
RE-THREAD LOWER TURRET MAZATROL
MILL TURNING MAZATROL
5-AXIS TOOL LENGTH COMP
SUB C-AXIS CONTROL
INVERSE TIME
3-D CO-OR ROT.
ATLM
POLAR COORDINATES INPUT
COMPARISON STOP
EIA CONVERSION
G54.1
SYNCH MILL TAPPING
FLASH TOOL
INCH/MM CONVERSION
ROT-AXIS SHAPE COMP
G00 SLOPE CONST
VARIABLE 600 SETS
CYLINDER
SIMUTANEOUS 5 AXIS
EIA HERICAL TAP CYCLE
EIA PATTERN CYCLE
THREAD CUT-SPEED OVERRIDE
COOLANT THRU MILLING HEAD
