MAZAK INTEGREX e420II-HS
Have one to sell?
ConditionUsed
1 available
THIS 2016 INTEGREX e-420HS HAS A MATRIX 2 CONTROL, (2) 12" KITAGAWA B-212 CHUCKS, FULL C-AXIS ON BOTH SPINDLES, 213 PSI COOLANT THRU AND HOBBING.
SPECIFICATIONS:
MAXIMUM SWING 26.38"
MAXIMUM SWING OVER CARRIAGE 26.38"
MAXIMUM CUTTING DIAMETER 26.38"
MAXIMUM CUTTING LENGTH 54.43"
MAIN SPINDLE SPECIFICATIONS (L)
NOSE A2-8
BORE 3.58"
MAXIMUM BAR DIAMETER 3.03"
SPEED 35-4000 RPM
INDEX (PROGRAMMABLE) 0.0001 DEGREE
HORSEPOWER (CONT./30 MINS.) 30/40 H.P. (A.C.)
TORQUE 533.8 FT/LBS
SECOND SPINDLE SPECIFICATIONS (R)
NOSE A2-8
BORE 3.58"
SPEED 35-4000 RPM
INDEX (PROGRAMMABLE) 0.0001 DEGREE
HORSEPOWER (CONT./30 MINS.) 30/40 H.P. (A.C.)
TORQUE (30 MINS.) 533.8 FT-LBS
UPPER TURRET AND TOOLING SPECIFICATIONS
TYPE OF TURRET 1 POSITION, W/ATC
TOOL SHANK HEIGHT 1.0"
TOOL SIZE (BORING BAR MAX. DIA.)1.5"
MAGAZINE CAPACITY 40 TOOLS
TOOL SELECTION METHOD RANDOM SHORTEST PATH
TOOL TO TOOL ATC TIME 1.3 SEC.
MAX. TOOL DIA. W/ALL POCKETS FULL 3.74"
MAX. TOOL DIA. W/ADJACENT POCKETS EMPTY 5.9"
MAX. TOOL LENGTH (FROM GAGE-LINE) 15.74"
MAXIMUM TOOL WEIGHT 26.5 LBS.
ATC TOOL SHANK BBT#40
ROTARY SPINDLE MOTOR TYPE IM
SPINDLE SPEED/RANGES 35-12,000 RPM / 1
SPINDLE HORSEPOWER (15 MIN.) 29.3 H.P. (A.C.)
TORQUE (15% ED) 200.4 FT-LBS
AXIS TRAVELS
ROTARY TOOL COUPLING CLAMP 15 DEG./24 POS.
B-AXIS 240 DEG. (0.0001 DEG. INCREMENTS, - 30 DEG. TO +210 DEG.)
X-AXIS UPPER 33.27"
Y-AXIS UPPER 16.54"
Z-AXIS UPPER 54.65"
SECOND HEADSTOCK W-AXIS 53.94"
AXIS RAPID RATES X/ Y & Z-AXIS 1969 IPM
SECOND HEADSTOCK W-AXIS 1181 IPM
B-AXIS 50 RPM
C-AXIS 555 RPM
1ST SPINDLE BORE 91MM (4000 RPM)
2ND SPINDLE BORE DIA. 91MM (4000 RPM)
TOTAL POWER REQUIRED (MACHINE ONLY) 83.29 KVA
NOTE ACTUAL MACHINE MAIN TRANSFORMER KVA RATING WILL BE GREATER.
AIR REQUIREMENTS 72 PSI / 15.7 CFM
MACHINE DIMS L 199.61" x W 133.66" x H 116.14"
MACHINE WEIGHT 44,092 LBS.
MAZATROL MATRIX 2 CONTROL
TOUCH SENSOR (RMP600) RADIO TYPE
12" KITAGAWA CHUCK B-212A0815 (1ST SPINDLE)
12" KITAGAWA CHUCK B-212A0815 (2ND SPINDLE)
CARDBUS I/F (2-SLOT)
LAN PORT
USB I/F
COMPLETE COOLANT SYSTEM
FULL COVERAGE CHIP AND COOLANT GUARD
ACTIVE VIBRATION CONTROL
INTELLIGENT THERMAL SHIELD
INTELLIGENT SAFETY SHIELD
VIRTUAL MACHINING
19" COLOR LCD
E-TOWER
1ST SPINDLE C-AXIS 0.0001 DEGREE INCR.
2ND SPINDLE C-AXIS 0.0001 DEGREE INCR.
B-AXIS 0.0001 DEG/CNTRING (REQ. EIA/ISO)
TURNING WITH POSITIONING B-AXIS
AUTO CHUCK JAW OPEN/CLOSE (1&2 SPINDLE)
HTD. CHUCK OPEN/CLOSE CONFIRM (1&2 SPIDLE)
CHUCK AIR BLAST (1ST & 2ND SPINDLE)
MAZA-CHECK
ABSOLUTE POSITIONING SYS (LINEAR AXES)
XYZ PITCH ERROR COMPENSATION INPUT
SWIVEL TYPE OPERATION CONTROL PANEL
COOLANT THRU MILLING HEAD
ATC AUTO RECOVERY
USER MACRO (COMMON VARIABLES 600 PAIRS)
MAZAK TAPPING/BORING TORNADO (EIA/ISO)
EIA/ISO CODE INPUT FUNCTION
G37.AUTO TLM (LASER ROT. TOOL MEAS. REQ)
ADD. EIA/ISO FUNCTIONS
INVERSE TIME FEED
SEQUENCE NUMBER COMPARISON STOP FUNCTION
TITLED WORKING PLANE
3-D COORDINATE CONVERSION
MAZACC-2D SOFTWARE (SHAPE COMPENSATION)
ADD. WORKPIECE COORDINATE SYST. 300 PARIS
THREAD CUTTING FUNCTION
POLAR COORDINATES INPUT (EIA)
EIA PATTERN CYCLE (GRID, ARC)
DIRECT ENTRY OF DRAWINGS DIMENSIONS
C1C2 SYNCHRONOUS FUNCTION
TOOL EYE (AUTOMATIC)
SCALE FEEDBACK SYSTEM Y,Y,Z AXIS)
MANUAL PULSE GENERATOR 1 (DETACHABLE)
HOBBING FUNCTION W/O TOOLING
TURRET AIR BLAST (FLOOD COOLANT NOZZLE)
15KG/213 PSI THRU CLNT/FLOOD CLNT SIMUL-FLOWABLE
AUTO POWER OFF (BREAKER TRIP)
OVERLOAD DETECTION SYSTEM
SIGNAL TOWER
CHIP CONVEYOR (SIDE, CONSEP) 1500U (60")
5-AXIS MACHINING PACKAGE
AUTO PECKING CYCLE WITH LOAD DETECTION
MILL-SPINDLE SYNCRO. TAPPING (W/O TOOL)
EIA/ISO CONV.
TOOL RADIUS COMPENSATION / 5-AXIS
EIA DYNAMIC COMPENSATION 2
MAXIMUM PROGRAM SIZE 8MB
ADDITIONAL M CODE
GOO SLOPE CONSTANT
SHAPE COMPENSATION FOR ROTARY AXES
INCH/METRIC CONVERSION
CYLINDRICAL & POLAR COORDINATE
WORK SETTING ERROR COMPENSATION
IC MEMORY CARD OPERATION
COMPACT FLASH CARD I/F + USB I/F (1-PORT)
SPINDLE SPEED 12,000 RPM (BBT#40)
