MAZAK QTN 100-II
Have one to sell?
ConditionUsed
1 available
THS 2010 QTN 100 HAS AN AUTOMATIC PARTS CATCHER, 118 PSI COOLANT THRU, CHIP CONVEYOR, 6" CHUCK AND MATRIX CONTROL
SPECIFICATIONS:
MAXIMUM SWING 21.6 IN
MAXIMUM CUTTING DIAMETER 11 IN
MAXIMUM MACHINING LENGTH. 12.1 IN
MAXIMUM BAR WORK SIZE 1.625 IN
X AXIS TRAVEL 7.5 IN
Z AXIS TRAVEL 13 IN
SPINDLE SPEED 6,000 RPM
SPINDLE NOSE A2-5
TURRET TYPE DRUM
TOOL CAPACITY 12
RAPID TRAVERSE X 1181 IPM
RAPID TRAVERSE Z 1299 IPM
STROKE OF TAILSTOCK BODY 13.7 IN
SPINDLE DRIVE MOTOR AC 10/ 15 HP
MACHINE WEIGHT 7270 LBS.
MAZATROL MATRIX NEXUS CONTROL
BARFEED PREPPED BAR PACKAGE
BAR FEEDER INTERFACE WITH I/O CARDS PLUS AUTO PARTS CATCHER
PARTS CATCHER 2" WIDE X 3.9" LONG
HIGH POWER COOLANT THRU - 118 PSI
CHIP CONVEYOR - SIDE DISPOSAL/HINGE TYPE
ALL AVAILABLE MANUALS
THS 2010 QTN 100 HAS AN AUTOMATIC PARTS CATCHER, 118 PSI COOLANT THRU, CHIP CONVEYOR, 6" CHUCK AND MATRIX CONTROL
Imperial
| Max. Swing | 21.6" |
| Max Turning Diameter | 11" |
| Spindle Bore/Max Bar Capacity | 1.97"/ 1.625" |
| Z Travel | 13" |
| X Travel | 7.5" |
| Machining Length | 12.1" |
| Chuck Size | 6" |
| Chuck Type | Hydraullic |
| Spindle Motor | 15 hp |
| Spindle Speeds (RPM) | 6000 |
| Spindle Bore/Bar Capacity | 1.97 in |
| Max. Bar Capacity | 1.625" |
| Turret Tool Positions | 12 |
| Tailstock | Yes |
| High Pressure Coolant System | 118 PSI |
| Chip Conveyor | Yes |
| Chip Conveyor | Side |
| Parts Catcher | Yes |
| Control | CNC (MAZATROL MATRIX NEXUS) |
| Weight | 7270 LBS |
SPECIFICATIONS:
MAXIMUM SWING 21.6 IN
MAXIMUM CUTTING DIAMETER 11 IN
MAXIMUM MACHINING LENGTH. 12.1 IN
MAXIMUM BAR WORK SIZE 1.625 IN
X AXIS TRAVEL 7.5 IN
Z AXIS TRAVEL 13 IN
SPINDLE SPEED 6,000 RPM
SPINDLE NOSE A2-5
TURRET TYPE DRUM
TOOL CAPACITY 12
RAPID TRAVERSE X 1181 IPM
RAPID TRAVERSE Z 1299 IPM
STROKE OF TAILSTOCK BODY 13.7 IN
SPINDLE DRIVE MOTOR AC 10/ 15 HP
MACHINE WEIGHT 7270 LBS.
MAZATROL MATRIX NEXUS CONTROL
BARFEED PREPPED BAR PACKAGE
BAR FEEDER INTERFACE WITH I/O CARDS PLUS AUTO PARTS CATCHER
PARTS CATCHER 2" WIDE X 3.9" LONG
HIGH POWER COOLANT THRU - 118 PSI
CHIP CONVEYOR - SIDE DISPOSAL/HINGE TYPE
ALL AVAILABLE MANUALS
