MAZAK QTN 200-II MY

SPECIFICATIONS:
CHUCK SIZE                   8"
MAXIMUM SWING                26.58"
STANDARD MACHINING DIAMETER  10.87"
MAXIMUM MACHINING DIAMETER   14.75"
MAXIMUM MACHINING LENGTH     21.28"
SPINDLE MOTOR                35 HP
STANDARD BAR CAPACITY        2.0"
SPINDLE SPEED                5,000
SPINDLE NOSE                 A2-6
SPINDLE BORE                 3"
TURRET TYPE                  MODIFIED VDI DRUM
NUMBER OF TOOLS              12
TOOL SIZE                    1" X 1" SQUARE
MILL SPINDLE POWER HP        7.5 (10 MIN)
TURRET INDEX TIME.(1 POS/FULL) (0.2 / 0.6)
X-AXIS TRAVE                 9.05"
Z-AXIS TRAVEL                22.63"
Y-AXIS TRAVEL                +/- 2"
RAPID TRAVERSE RATES X-AXIS  1181 IPM
RAPID TRAVERSE RATES Z-AXIS  1300 IPM
RAPID TRAVERSE RATES Y-AXIS  826.8 IPM
TAILSTOCK CENTER             MT#5
MACHINE HEIGHT               72.44"
FLOOR SPACE REQUIREMENT      106.81" X 73.23"
WEIGHT                       10,802 LBS
