MAZAK QTN 250

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES 2 AXIS
Manufacturer:
MAZAK
Model:
QTN 250
Year:
2005
Stock #:
4844
Status:
For Sale
Serial #:
178450

Description

THIS QTN 250 HAS A 10" HYDRAULIC CHUCK WITH 3" BAR CAP, NEXUS 640T CONTROL, TAILSTOCK AND A 35HP/ 4000 RPM SPINDLE.

Max. Swing26.5"673.1 mm
Max Turning Diameter14.75"374.65 mm
Spindle Bore/Max Bar Capacity3.46"/ 3.03"3.46"/ 3.03"
Z Travel22.63"574.8 mm
X Travel9.05"229.87 mm
Machining Length19.9"505.46 mm
Chuck Size10"254 mm
Chuck TypeHydraullicHydraullic
Spindle Motor35 hp
Spindle Speeds (RPM)40004000
Spindle Bore3.46 in
Max. Bar Capacity3.03"76.962 mm
Turret Tool Positions1212
TailstockYesYes
Chip ConveyorYesYes
Chip ConveyorSideSide
ControlCNC (MAZATROL NEXUS 640T)CNC (MAZATROL NEXUS 640T)
Dimensions115" x 70" x 72"115" x 70" x 72"
Weight11,500 LBS11,500 LBS

SPECIFICATIONS:
MAXIMUM SWING                          26.5"
MAXIMUM TURNING DIAMETER               14.75"
MAXIMUM MACHINING LENGTH               19.9"
X AXIS TRAVEL                          9.05"
Z AXIS TRAVEL                          22.63"
RAPID TRAVERSE RATE X & Z AXES         1181 IPM
BAR CAPACITY                           3.03"
SPINDLE BORE                           3.46"
SPINDLE SPEED, MAX.                    4000 RPM
SPINDLE NOSE                           A2-8
SPINDLE MOTOR                          35 HP
TURRET CAPACITY                        12 STATION TURRET
MACHINE WEIGHT (APPROX.)               11,500 LBS
MACHINE DIMENSIONS (APPROX.)           115" x 70" x 72"

MAZATROL NEXUS 640T
WINDOWS 2000 OPERATING SYSTEM
10" HYDRAULIC CHUCK
TAILSTOCK
MULTITAP TRANSFORMER
CHIP CONVEYOR SIDE DISP.(HINGE) 500U
ALL AVAILABLE TOOLING AND MANUALS
