MAZAK QTN 300-II
Have one to sell?
ConditionUsed
1 available
THIS QTN 300 HAS A 12" HYDRAULIC CHUCK WITH 3" BAR CAP, MATRIX CONTROL, 213 PSI COOLANT THRU TAILSTOCK, PARTS CATCHER AND A 35HP/ 4000 RPM SPINDLE.
SPECIFICATIONS:
MAXIMUM SWING 26.77"
STANDARD MACHINING DIAMETER 10.39"
MAXIMUM MACHINING DIAMETER 16.54"
SPINDLE MOTOR 35/30 (30 MIN/CONT)
SPINDLE BORE 3.46"
STANDARD BAR CAPACITY 3"
SPINDLE SPEED 4000 RPM
SPINDLE NOSE A2-8
TURRET TYPE DRUM TURRET
NUMBER OF TOOLS 12
TOOL SHANK HEIGHT 1"
BORING BAR SHANK DIAMETER 1.5"
TURRET INDEX TIME 0.2 SEC (ONE POSITION)
X-AXIS TRAVEL 8.85"
Z-AXIS TRAVEL (48) 49"
RAPID TRAVERSE RATES X-AXIS 1,181 IPM
RAPID TRAVERSE RATES Z-AXIS 984 IPM
TAILSTOCK CENTER MT NO. 5
MACHINE HEIGHT 78.73"
FLOOR SPACE REQUIREMENT
48" BED 135.8" X 80.71"
WEIGHT (48" BED) 15,620 LBS.
MAZATROL MATRIX NEXUS CONTROL
12.1 COLOR LCD
USB I/F (2-PORT) / LAN PORT
USER MACRO (COMMON VARIABLES: 600 PAIRS)
EIA/ISO INPUT FUNCTION
SEQUENCE NUMBER COMPARISON STOP FUNCTION
AUTOMATIC TOOL EYE
213 PSI HIGH-POWER COOLANT
12 POSITION DRUM TURRET BOLT ON STYLE TOOLING
PROGRAMMABLE TAILSTOCK LIVE CENTER W/DEAD QUILL
WINDOWS XP OPERATING SYSTEM FOR MAZAK MACHINE CONTROL
12 THRU HOLE CHUCK 3000 RPM WITH 3 BAR CAP.
PARTS CATCHER
RE-THREADING
THREAD START POINT COMPENSATION
CHIP CONVEYOR SIDE 1200U (48) (HINGE)
ALL AVAILABLE TOOLING AND MANUALS*BUYERS RESPONSIBILITY TO VERIFY ALL SPECIFICATIONS AND DIMENSIONS
