MAZAK QTN 350-II MSY

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
QTN 350-II MSY
Year:
2010
Stock #:
4533
Status:
For Sale
Serial #:
221934

Description

THIS QTN 350MSY HAS A MATRIX NEXUS CONTROL, 12" CHUCK WITH 4" THROUGH HOLE AND 213 PSI COOLANT THRU.

Maximum Swing29.5"749.3 mm
Max Turning Diameter16.5"419.1 mm
Main Spindle Bore/Max Bar Capacity4.41/ 4.04.41/ 4.0
Tail Stock/Sub SpindleSub SpindleSub Spindle
X-Axis Travel (X1, X2, X3)10.7510.75
Z-Axis Travel (Z1, Z2, Z3)26.2526.25
Y-Axis Travel (Y1, Y2, Y3)4"4"
C-Axis Indexing (1, 2)0.00010.0001
W-Axis Travel Sub Spindle26.25 in
Main Spindle Chuck Size12"304.8 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter4.4"111.76 mm
Main Spindle Maximum Bar Work4.02"102.11 mm
Main Spindle Speed4,000 RPM4,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)2525
Sub Spindle/2nd Spindle Chuck Size1010
Sub Spindle/2nd Spindle Bore Size3.563.56
Sub Spindle/2nd Spindle Chuck TypeHydraulicHydraulic
Sub Spindle/2nd Spindle Speed4,000 RPM4,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)2525
Turret Tool Positions 1, 21212
Turret Rotary Tool Spindle Speed 1, 240004000
Turret Rotary Tool Horse Power 1, 21010
Chip ConveyorYesYes
Milling Spindle Synchronous TappingYesYes
Tool Eye Automatic Front SpindleYesYes
Tool Eye Automatic Second SpindleYesYes
Tool Eye Measurement Upper TurretYesYes
High Pressure Coolant System (PSI)213213
ControlCNC (MAZATROL MATRIX NEXUS)CNC (MAZATROL MATRIX NEXUS)
Dimensions146.3" X 95.3" X 85.4"146.3" X 95.3" X 85.4"
Weight14,990 LBS14,990 LBS

SPECIFICATIONS:
MAXIMUM SWING                        29.5”
MAXIMUM MACHINING DIAMETER           16.5”
BAR WORK CAPACITY                    4.02”
MAX SUPPORT WEIGHT (INCLUDING CHUCK) 1,433 LBS (MAIN) / 881 LBS (2ND)
MAIN SPINDLE:
SPINDLE SPEED                        35 – 3,300 RPM
SPINDLE NOSE                         A2-11
SPINDLE THROUGH-HOLE DIAMETER        4.41”
SPINDLE MOTOR (30 MIN/CONT)          40/30 HP
SPINDLE TORQUE                       596 FT/LBS
SECONDARY SPINDLE:
CHUCK SIZE                           10”
SPINDLE SPEED                        35 – 4,000 RPM
SPINDLE NOSE                         A2-8
MOTOR OUTPUT                         25 HP
NUMBER OF TOOLS                      12
TOOL SIZE TURNING (OUTSIDE/INSIDE)   1” / 2”
INDEXING TIME (NEXT/OPPOSITE)        0.25/0.8 SEC
MILL SPINDLE SPEED                   4,000 RPM
MILLING MOTOR OUTPUT                 10 HP
MAXIMUM TORQUE OF MILLING SPINDLE    70 FT/LBS
TRAVEL X                             10.75”
TRAVEL Y                             4”
TRAVEL Z (26”)                       26.25”
TRAVEL W (26”)                       25.625”
RAPID TRAVERSE (X/Y/Z/W)             1181 IPM
MACHINE HEIGHT                       85.4”
MACHINE WIDTH                        95.3”
MACHINE LENGTH (26”)                 146.3”
MACHINE WEIGHT (26”)                 14,990 LBS

MAZATROL MATRIX NEXUS CONTROL
12.1" COLOR LCD
USB I/F (2-PORT)
LAN PORT
USER MACRO (COMMON VARIABLES:  600 PAIRS)
MAZAK TAPPING/BORING TORNADO   MXN-043MT EIA HELICAL TAP CYCL
EIA/ISO INPUT FUNCTION
SEQUENCE NUMBER COMPARISON  STOP FUNCTION
ABSOLUTE POSITIONING SYS (N/A  WITH S/F)
TOOL EYE (AUTOMATIC)
213 PSI HIGH-POWER COOLANT
OPERATOR DOOR INTERLOCK WITH  LOCK-SWITCH
HYDRAULIC PRESSURE INTERLOCK
Y-AXIS CONTROL
12 POSITION VDI TURRET
ROTARY-TOOL SPINDLE SPEED  4000RPM/9.4KGM
MILLING-SPINDLE SYNCHRONOUS TAPPING
C-AXIS 0.0001 DEGREE INCR.
MAIN SPINDLE MOTOR AC  30KW(40HP)
SPINDLE SPEED 3300 RPM
SPINDLE BORE DIA.112MM(4.4")
12"THRU-HOLE CHUCK 4" BAR CAP. B212A1115A (SS2110 CYLINDER)
SECOND SPINDLE SPEED 4000 RPM
SECOND SPINDLE MOTOR AC18.5KW (25HP)
2ND SPINDLE C-AXIS .0001 DEG.
INCLUDING EIA INPUT FUNCTION
10" THRU-HOLE CHUCK  B210A0815(2ND SPDL.)
CHUCK OPEN/CLOSE CONFIRMATION (1 & 2 SPINDLE)
AUTO CHUCK JAW OPEN CLOSE (1 & 2 SPINDLE)
CHUCK AIR BLAST (SECOND SPNDL)
RELOCATION DEVICE
WINDOWS XP OPERATING SYSTEM  FOR MAZAK MACHINE CONTROL.
CHIP CONVEYOR SIDE (26") DISPOSAL(HINGE) 650U
RE-THREADING
THREAD START POINT  COMPENSATION
