MAZAK QTN 400-II M CNC LATHE W/MILLING

SPECIFICATIONS:
STANDARD CHUCK SIZE          12"
MAX. SWING                   33.268"
STANDARD MACHINING DIAMETER  13.228"
MAX. MACHINING DIAMETER      22.835"
STANDARD BAR CAPACITY        4.016"
MAX. SUPPORT WT (CHUCK/SHAFT)2,205 LBS/2923 LBS
SPINDLE MOTOR (30 MIN/CONT)  50/40 HP
SPINDLE BORE                 5.197"
SPINDLE SPEED                2,500 RPM
SPINDLE NOSE                 A2-11
NUMBER OF TOOLS              12 POSITION VDI TURRET
TOOL SIZE (OUTSIDE/INSIDE)   1.26"/2.0"
TURRET INDEX TIME (ONE/FULL) 0.25 SEC/0.8 SEC.
MILL SPINDLE MOTOR           10 HP
MILL SPINDLE SPEED           4,000 RPM
C-AXIS                       0.0001 DEG INC
X-AXIS TRAVEL                12.13"
Z-AXIS TRAVEL                83.5"
COOLANT TANK CAPACITY        11.3 GAL
MACHINE WEIGHT (APPROX)      22,267 LBS.
MOTOR SPECIFICATIONS:        50 HP MAIN SPINDLE DRIVE MOTOR
                             10 HP LIVE MILLING MOTOR
