MAZAK QTN 450-II MY

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
QTN 450-II MY
Year:
2011
Stock #:
5647
Status:
For Sale

Description

THIS QTN 450MY HAS A MATRIX NEXUS CONTROL, 80" CENTERS, 21" KITAGAWA HYDRAULIC CHUCK WITH 6.5" BORE, SMW STEADY REST AND MAZAK SUPERFLOW COOLANT THRU.

Maximum Swing33.27"845.06 mm
Max Turning Diameter23.8"604.52 mm
Main Spindle Bore/Max Bar Capacity7.2/ 6.57.2/ 6.5
Tail Stock/Sub SpindleTail StockTail Stock
Maximum Cutting Length81.67"2,074.4 mm
X-Axis Travel (X1, X2, X3)13.3713.37
Z-Axis Travel (Z1, Z2, Z3)81.6781.67
Y-Axis Travel (Y1, Y2, Y3)+/- 4"+/- 4"
C-Axis Indexing (1, 2)0.00010.0001
Main Spindle Chuck Size21"533.4 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter7.24"183.9 mm
Main Spindle Maximum Bar Work6.5"165.1 mm
Main Spindle Speed2,000 RPM2,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)5050
Turret Tool Positions 1, 21212
Turret Rotary Tool Spindle Speed 1, 240004000
Turret Rotary Tool Horse Power 1, 21010
Steady RestYesYes
Chip ConveyorYesYes
Coolant Thru Milling HeadYesYes
High Pressure Coolant System (PSI)10001000
ControlCNC (MAZATROL MATRIX NEXUS)CNC (MAZATROL MATRIX NEXUS)
Dimensions25.5’ X 9’ X 8.5’25.5’ X 9’ X 8.5’
Weight34,000 LBS34,000 LBS

SPECIFICATIONS:
CHUCK DIAMETER       21"
SWING OVER BED       33.27"
TURNING LENGTH       81.67"
X AXIS               13.37"
Z AXIS               81.67"
Y AXIS               8” (591 IPM)
RAPID TRAVERSE X/Z   1,181 IPM
SPINDLE NOSE         A2-15
SPINDLE BORE         6.5”
SPINDLE SPEEDS       4 – 2,000 RPM
MOTOR                50 HP
TAILSTOCK QUILL TAPER MT#5
TAILSTOCK QUILL DIAM 5"
TAILSTOCK TRAVEL     72.5"
APPROXIMATE WEIGHT   34,000 LBS
FLOOR SPACE          25.5’ X 9’ X 8.5’ HIGH

MAZATROL MATRIX NEXUS CNC CONTROL
21" KITAGAWA HYDRAULIC CHUCK MODEL BB-221
SMW AUTOBLOCK HYDRAULIC SELF CENTERING STEADY REST MODEL K4 (2” TO 11” CAPACITY)
PROGRAMMABLE TAILSTOCK
CHIP CONVEYOR
HIGH PRESSURE COOLANT SYSTEM (MAZAK SUPERFLOW)
