MAZAK QTN 450-II M /1000 CNC 3 AXIS W/MILLING
Have one to sell?
ConditionUsed
1 available
THIS QTN 450M HAS A MATRIX CONTROL, 18" KITAGAWA HYDRAULIC CHUCK, WITH A 6.625" BAR CAPACITY, 40" CENTERS AND TAILSTOCK.
SPECIFICATIONS:
MAXIMUM SWING OVER BED 33.268"
MAX. CUTTING DIAMETER 23"
MAX. CUTTING LENGTH 38.69"
SPINDLE NOSE A2-15"
SPINDLE BORE MAIN 7.24"
MAX. BAR CAPACUITY 6.625"
SPINDLE SPEEDS 2000 RPM
SPINDLE TORQUE 1217 FT-LBS.
MAIN MOTOR 50 HP AC
X - AXIS TRAVEL 13.375"
Z - AXIS TRAVEL 40.13"
C - AXIS TRAVEL .001 DEGREE INDEXING
RAPID TRAVERSE RATE X , Z 1181 IPM, 1299 IPM
C 555 RPM
TURRET POSITIONS / MODIFIED VDI 12 POSITION
ROTARY TOOL SPINDLE SPEEDS 4000 RPM
ROTARY TOOL HORSEPOWER 10 HP
TAILSTOCK CONTROL FULLY PROGRAMABLE
TAILSTOCK CENTER MT # 5
STROKE OF TAIL BODY 36.4"
MACHINE WEIGHT 22,417 LBS.
MAZATROL MATRIX CNC CONVERSATIONAL CONTROL
12.1 COLOR MONITOR / EIA 3D COMP
18" 3-JAW KITAGAWA HYDRAULIC CHUCK SYSTEM
3.5 FLOPPY DISC ABSOLUTE POSITIONING SYSTEM
AUTOMATIC TOOL EYE
BACKGROUND PATH CHECK
COMPARISON STOP
PITCH ERROR COMP
EIA/ISO OPTION PACKAGE
USB/LAN / EXT-DATA I/O
HIGH PRESSURE COOLANT 213 PSI
PROGRAMABLE TAILSTOCK
RETHREADING
THREAD START POINT COMP
ROTARY HEADS (3)
SYNC TAP ON MILL HEAD / G54.1
VARIABLE 600 SETS/ TILTED WORK PLANE/ CYLINDER
CHIP CONVEYOR
ALL AVAILABLE MANUALS
ALL AVAILABLE TOOL HOLDERS
THIS QTN 450M HAS A MATRIX CONTROL, 18" KITAGAWA HYDRAULIC CHUCK, WITH A 6.625" BAR CAPACITY, 40" CENTERS AND TAILSTOCK.
Imperial
| Maximum Swing | 33.268" |
| Max Turning Diameter | 23" |
| Main Spindle Bore/Max Bar Capacity | 7.24/ 6.625 |
| Tail Stock/Sub Spindle | Tail Stock |
| Maximum Cutting Length | 38.69" |
| X-Axis Travel (X1, X2, X3) | 13.375 |
| Z-Axis Travel (Z1, Z2, Z3) | 40.13 |
| C-Axis Indexing (1, 2) | .001 DEGREE INDEXING |
| Main Spindle Chuck Size | 18" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 7.24" |
| Main Spindle Maximum Bar Work | 6.625" |
| Main Spindle Speed | 2,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 50 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 4000 |
| Turret Rotary Tool Horse Power 1, 2 | 10 |
| Chip Conveyor | Yes |
| Number of Available Live Tool Holders | 3 |
| Control | CNC (MAZATROL MATRIX) |
| Weight | 22,417 LBS |
SPECIFICATIONS:
MAXIMUM SWING OVER BED 33.268"
MAX. CUTTING DIAMETER 23"
MAX. CUTTING LENGTH 38.69"
SPINDLE NOSE A2-15"
SPINDLE BORE MAIN 7.24"
MAX. BAR CAPACUITY 6.625"
SPINDLE SPEEDS 2000 RPM
SPINDLE TORQUE 1217 FT-LBS.
MAIN MOTOR 50 HP AC
X - AXIS TRAVEL 13.375"
Z - AXIS TRAVEL 40.13"
C - AXIS TRAVEL .001 DEGREE INDEXING
RAPID TRAVERSE RATE X , Z 1181 IPM, 1299 IPM
C 555 RPM
TURRET POSITIONS / MODIFIED VDI 12 POSITION
ROTARY TOOL SPINDLE SPEEDS 4000 RPM
ROTARY TOOL HORSEPOWER 10 HP
TAILSTOCK CONTROL FULLY PROGRAMABLE
TAILSTOCK CENTER MT # 5
STROKE OF TAIL BODY 36.4"
MACHINE WEIGHT 22,417 LBS.
MAZATROL MATRIX CNC CONVERSATIONAL CONTROL
12.1 COLOR MONITOR / EIA 3D COMP
18" 3-JAW KITAGAWA HYDRAULIC CHUCK SYSTEM
3.5 FLOPPY DISC ABSOLUTE POSITIONING SYSTEM
AUTOMATIC TOOL EYE
BACKGROUND PATH CHECK
COMPARISON STOP
PITCH ERROR COMP
EIA/ISO OPTION PACKAGE
USB/LAN / EXT-DATA I/O
HIGH PRESSURE COOLANT 213 PSI
PROGRAMABLE TAILSTOCK
RETHREADING
THREAD START POINT COMP
ROTARY HEADS (3)
SYNC TAP ON MILL HEAD / G54.1
VARIABLE 600 SETS/ TILTED WORK PLANE/ CYLINDER
CHIP CONVEYOR
ALL AVAILABLE MANUALS
ALL AVAILABLE TOOL HOLDERS
