MORI SEIKI NT 4300 DCG-1500SZ 5 AXIS LATHE

SPECIFICATIONS:
SWING OVER BED               28.7 IN
MAX. TURNING DIAMETER        25.9 IN
MAX. TURNING LENGTH          58.9 IN
X1 AXIS TRAVEL               29.5 IN.
Z1 AXIS TRAVEL               61.02 IN.+ 3.94 IN
Y-AXIS TRAVEL                +/- 8.3 IN.
B-AXIS TOTAL INDEXING RANGE  +/- 120 DEGREES
X2 AXIS TRAVEL               7.68 IN
Z2 AXIS TRAVEL               60.04 IN
SPINDLE SPEED                3000 RPM
SPINDLE NOSE                 A2-8 IN.
SPINDLE BORE                 4.1 IN.
2ND SPINDLE SPEED            3000 RPM
TOOL POSITIONS               100 ATC
TOOLING TYPE                 CAPTO C6
2ND TURRET TOOL POSITIONS    12
ROTARY TOOL SPEED            12,000 RPM
RAPID TRAVERSE RATE
X1 & Z1-AXIS                 1968.5 IPM
X2 & Z2-AXIS                 1181.1 IPM
Y-AXIS                       1181.1 IN
SPINDLE MOTOR                30 HP
