**SOLD** OKUMA VTM-100 40" 3-AXIS CNC VTL WITH LIVE MILLING **SOLD**
Have one to sell?
ConditionUsed
1 available
THIS OKUMA VTM-100 3-AXIS CNC VTL WITH LIVE MILLING HAS A 36 STATION ATC, 31.5" CHUCK, C-AXIS TABLE ROTATION. IT SWINGS 40" AND COMES WITH A NICE TOOLING PACKAGE INCLUDING 5 LIVE.
SPECIFICATIONS:
MAXIMUM SWING DIAMETER 39.37"
MAXIMUM TURNING LENGTH 33.07
DISTANCE FROM SPINDLE NOSE TO FLOOR 45.3"
TOOL TYPE CAT 50
SPINDLE SPEEDS (2-SPEED) 3-1250 RPM
SPINDLE MOTOR 40 HP 30 HP
X-AXIS TRAVEL 25.6"
Z-AXIS TRAVEL 33.1"
C-AXIS INDEXING .001 DEG.
C-AXIS ACCURACY +/- .01 DEG.
MILLING MOTOR 10 HP 7.5 HP
MILLING SPINDLE SPEEDS 10-4500 RPM
RAPID TRAVERSE, X/Z AXES 630 IPM
CUTTING FEED RATE .0001-18.19 IPR
FLOOR SPACE REQUIRED 162" X 144"
MACHINE HEIGHT 169"
TOTAL WEIGHT 29,700 LBS.
OKUMA OSP- CNC CONTROL
RAM WITH LIVE MILLING
36 STATION AUTOMATIC TOOL CHANGER
31.5" CHUCK
C-AXIS TABLE ROTATION
CHIP BLASTER
BOX WAYS
CHIP CONVEYOR
OVER 40 TOOLS INCLUDED - 5 LIVE
THIS OKUMA VTM-100 3-AXIS CNC VTL WITH LIVE MILLING HAS A 36 STATION ATC, 31.5" CHUCK, C-AXIS TABLE ROTATION. IT SWINGS 40" AND COMES WITH A NICE TOOLING PACKAGE INCLUDING 5 LIVE.
Imperial
| Table Dia | 40" |
| Maximum Swing | 39.37" |
| Maximum Turning Diameter | 33.07" |
| Maximum Turning Height | 45.0 |
| Vertical Travel of Ram, Z-Axis | 33.1" |
| Horizontal Railhead Travel, X-Axis | 25.6 |
| Main Table Motor | 40/ 30 HP |
| Live Spindle Motor | 10/ 7.5 HP |
| Live Spindle Speed, 2-Ranges | 10 - 4500 RPM |
| C-Axis Contouring | .001 |
| Cutting Feed Rate | 18.19 |
| Automatic Tool Changer | 36 |
| Tool Shank | CAT 50 |
| Control | CNC (OKUMA OSP) |
| Dimensions | 162" X 144" X 169" |
| Weight | 29,700 LBS |
SPECIFICATIONS:
MAXIMUM SWING DIAMETER 39.37"
MAXIMUM TURNING LENGTH 33.07
DISTANCE FROM SPINDLE NOSE TO FLOOR 45.3"
TOOL TYPE CAT 50
SPINDLE SPEEDS (2-SPEED) 3-1250 RPM
SPINDLE MOTOR 40 HP 30 HP
X-AXIS TRAVEL 25.6"
Z-AXIS TRAVEL 33.1"
C-AXIS INDEXING .001 DEG.
C-AXIS ACCURACY +/- .01 DEG.
MILLING MOTOR 10 HP 7.5 HP
MILLING SPINDLE SPEEDS 10-4500 RPM
RAPID TRAVERSE, X/Z AXES 630 IPM
CUTTING FEED RATE .0001-18.19 IPR
FLOOR SPACE REQUIRED 162" X 144"
MACHINE HEIGHT 169"
TOTAL WEIGHT 29,700 LBS.
OKUMA OSP- CNC CONTROL
RAM WITH LIVE MILLING
36 STATION AUTOMATIC TOOL CHANGER
31.5" CHUCK
C-AXIS TABLE ROTATION
CHIP BLASTER
BOX WAYS
CHIP CONVEYOR
OVER 40 TOOLS INCLUDED - 5 LIVE
