MAZAK FH 680 /4/5 AXIS
Have one to sell?
ConditionUsed
1 available
THIS FH 680 IS A 5 AXIS HORIZONTAL WITH (2) 24.8" PALLETS AND 2 EXTRA TABLES, THRU SPINDLE COOLANT AND A CAT 50/ 15000 RPM SPINDLE.
SPECIFICATIONS:
PALLET SIZE(2) 24.8"
X AXIS TRAVEL 41.94"
Y AXIS TRAVEL 31.50"
Z AXIS TRAVEL 32.4"
PALLET TOP TO SPINDLE CENTER 3.93"-35.4"
PALLET CENTER TO SPINDLE NOSE 7.87"-40.35"
PALLET LOAD CAPACITY 3300 LBS
PALLET INDEX .001°
SPINDLE TAPER #50
SPINDLE SPEEDS 15,000 RPM
RAPID TRAVERSE 1280 IPM
CUTTING FEED RATE 0.04-1260 IPM
TOOL MAGAZINE STORAGE 80 ATC
MAX. TOOL DIAMETER 5.31"/19.68"
MAIN MOTOR 40 HP
DIMENSIONS 134"W X 270"L-R X 132" HT.
MAZATROL M PLUS CONTROL
4TH AND 5TH AXIS CAPABILITY
2 EXTRA TABLES
THRU COOLANT
JORGENSON CHIP CONVEYOR
ALL AVAILABLE MANUALS
THIS FH 680 IS A 5 AXIS HORIZONTAL WITH (2) 24.8" PALLETS AND 2 EXTRA TABLES, THRU SPINDLE COOLANT AND A CAT 50/ 15000 RPM SPINDLE.
Imperial
| X-AXIS TRAVEL | 41.94" |
| Y-AXIS TRAVEL | 31.5" |
| Z-AXIS TRAVEL | 32.4" |
| SPINDLE TAPER | CAT 50 |
| SPINDLE DRIVE MOTOR | 40 hp |
| SPINDLE SPEED | 15000 rpm |
| TOOL CAPACITY (ATC) | 80 |
| NUMBER OF PALLETS | 2 |
| PALLET SIZE | 24.8" x 24.8" |
| PALLET SIZE (W) | 24.8" |
| PALLET SIZE (L) | 24.8" |
| PALLET LOAD CAPACITY | 3300 lb |
| 4 AXIS PALLET TABLE INDEXING | .001 |
| 5 AXIS PROGRAMMABLE AXIS'S | 5 |
| TOOL PROBE/AUTO TOOL LENGTH MEASURE | Yes |
| CHIP CONVEYOR | Yes |
| Control | CNC (MAZATROL M PLUS) |
| Dimensions | 134" X 270" X 132" |
SPECIFICATIONS:
PALLET SIZE(2) 24.8"
X AXIS TRAVEL 41.94"
Y AXIS TRAVEL 31.50"
Z AXIS TRAVEL 32.4"
PALLET TOP TO SPINDLE CENTER 3.93"-35.4"
PALLET CENTER TO SPINDLE NOSE 7.87"-40.35"
PALLET LOAD CAPACITY 3300 LBS
PALLET INDEX .001°
SPINDLE TAPER #50
SPINDLE SPEEDS 15,000 RPM
RAPID TRAVERSE 1280 IPM
CUTTING FEED RATE 0.04-1260 IPM
TOOL MAGAZINE STORAGE 80 ATC
MAX. TOOL DIAMETER 5.31"/19.68"
MAIN MOTOR 40 HP
DIMENSIONS 134"W X 270"L-R X 132" HT.
MAZATROL M PLUS CONTROL
4TH AND 5TH AXIS CAPABILITY
2 EXTRA TABLES
THRU COOLANT
JORGENSON CHIP CONVEYOR
ALL AVAILABLE MANUALS
