MAZAK HCN 6800-II /FULL 4TH AXIS
Have one to sell?
ConditionUsed
1 available
WELL MAINTAINED 2015 HCN 6800 HAS (2) 24.8" PALLETS, MATRIX 2 CONTROL, 80 ATC, FULL 4TH AXIS, 1000 PSI COOLANT THRU AND CAT 50/ 8000 RPM SPINDLE.
SPECIFICATIONS:
TABLE SIZE L X W (IN.) 24.8" X 24.8"
MAX. WORKPIECE WEIGHT (LBS) 3,307
PALLET CHANGER NO. OF PALLET 2
INDEX TABLE INDEX DEGREES FULL 4TH
TAPER CAT #50
TOP RPM 10,000
HORSE POWER (30 MIN RATING) 50
# SPEED RANGES 2
NUMBER OF TOOLS 80 ATC
TOOL CHANGE TIME C-TO-C (SEC) 4.2
MAX. TOOL LENGTH (IN.) 24.8"
MAX. TOOL DIAMETER (IN.) 9.84" (MAX TOOL DIA UPGRADE 12")
MAX. TOOL WEIGHT 66 LBS
NUMBER OF AXES: 4
X AXIS 41.340"
Y AXIS 35.430"
Z AXIS 38.580"
MAX FEED AND RAPID RATES
X, Y, Z, 2,362 IPM 2,362 IPM
MACHINE DIMENSIONS 248" X 130" X 134"
MACHINE WEIGHT (LBS) 41,800
MATRIX NEXUS 2 CONTROL
HIGH SMOOTHING CONTROL (REQUIRES MAZACC-3D)
80 TOOL CHAIN MAG CAT50
ADDITIONAL WORK LIGHT
RENISHAW OMP60M OPTICAL PROBE PREP
NC ROTARY TABLE
DYNAMIC COMPENSATION 2,1 (ONLY NC-TABLE)
MAZACC-3D HIGH SPEED SOFTWARE PACKAGE (G61.1 & GO5P2)
SHAPE COMP FOR ROTARY AXIS (REQUIRES NC ROTARY TABLE)
COOLANT THROUGH SPINDLE 12GPM 1000PSI APPLICATION
MAZAK SUPER FLOW V8M VARIABLE HIGH PRESSURE COOLANT UNIT
CHIP CONVEYOR
FULL SET OF PAPER MANUALS
