MAZAK PFH 5800 HORIZONTAL W/ FULL 4TH AXIS

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
MACHINING CENTERS, HORIZONTAL
Manufacturer:
MAZAK
Model:
PFH 5800
Year:
2005
Stock #:
4831
Status:
For Sale
Serial #:
176866

Description

THIS PFH 5800 COMES WITH (2) 19.69" PALLETS, FUSION 640M CONTROL, FULL 4TH AXIS, 230 PSI COOLANT THRU SPINDLE AND 80 TOOL ATC.

X-AXIS TRAVEL28.74"730 mm
Y-AXIS TRAVEL28.74"730 mm
Z-AXIS TRAVEL29.13"739.9 mm
SPINDLE TAPERCAT 40CAT 40
SPINDLE SPEED10,000 RPM10000 rpm
TOOL CAPACITY (ATC)8080
NUMBER OF PALLETS22
PALLET SIZE19.69" x 19.69"19.69" x 19.69"
PALLET SIZE (W)19.69"500.13 mm
PALLET SIZE (L)19.69"500.13 mm
PALLET LOAD CAPACITY1543 lb
4 AXIS PALLET TABLE INDEXINGN/C ContouringN/C Contouring
PART PROBEYESYES
TOOL PROBE/AUTO TOOL LENGTH MEASUREYesYes
HI-PRESSURE COOLANT SYSTEM213 psi
CHIP CONVEYORYesYes
ControlCNC (MAZATROL FUSION 640M)CNC (MAZATROL FUSION 640M)
Weight25,550 LBS25,550 LBS

SPECIFICATIONS:
NUMBER OF AXIS          4
PALLET SIZE             19.69" X 19.69"
PALLET CAPACITY         1,543 LBS
PALLET INDEXING/B-AXIS  0.001 DEG
X-AXIS TRAVEL           28.74"
Y-AXIS TRAVEL           28.74"
Z-AXIS TRAVEL           29.13"
SPINDLE SPEED           10,000 RPM
SPINDLE TAPER           40
TOOL CHANGER CAPACITY   80
MACHINE WEIGHT          25500 LBS

MAZATROL FUSION 640M CNC CONTROL
FULL 4TH AXIS
CHIP CONVEYOR
COOLANT THRU SPINDLE (230 PSI)
AUTO TOOL LENGTH MEASUREMENT
COOLANT TANK & PUMP
80 STATION TOOLCHANGER
RENISHAW PROBING
