NIIGATA MPN 80 4-AXIS HORIZONTAL MACHINING CENTER W/8 PALLET POOL
Have one to sell?
ConditionUsed
1 available
THIS NIIGATA MPN 80 4-AXIS HORIZONTAL MACHINING CENTER HAS AN 8 PALLET POOL WITH 250 STATION ATC, 3 AND 4 SIDED TOMBSTONES, FULL 4TH AXIS AND A CAT 50/ 15000 RPM SPINDLE.
SPECIFICATIONS:
NUMBER OF PALLETS 8
PALLET SIZE 31.5" X 31.5"
TABLE LOAD CAPACITY 4,400 LBS
AXIS TRAVEL X - AXIS 59.1
Y - AXIS 44.1"
Z - AXIS 48.0"
B - AXIS .001 DEGREE
RAPID TRAVERSE 1575 IPM
CUTTING FEEDRATE .04-1575 IPM
SPINDLE CENTER TO PALLET SURFACE 3.1- 47.7"
SPINDLE NOSE TO TABLE CENTER 7.9"-55.9"
SPINDLE DRIVE MOTOR 60 HP AC
SPINDLE TORQUE 300 FT-LBS
SPINDLE TAPER CAT # 50
SPINDLE SPEEDS 15,000 RPM
AUTO TOOL CHANGE 250 ATC
TOOL LENGTH 24.0"
MAX. DIA. 5.1"/9.45"
TOOL CHANGE TIME 2.5 SEC.
CHIP TO CHIP 7.9 SEC.
MACHINE WEIGHT 48,500 W/O APC
FANUC 16iM 32 BIT CNC CONTROL
2MB EXT MEMORY (16,800 FT.)
RS 232 PORT
250 AUTO TOOL CHANGERS
15,000 RPM SPINDLE.
60 HP SPINDLE
.001 NC ROTARY TABLE
CHIP BLASTER 1000 PSI CTS SYSTEM
COOLANT FILTRATION SYSTEM WITH CHIP CONVEYOR FOR ALUMINUM
OVERHEAD SHOWER COOLANT
WORK PIECE WASH GUNS (2 SIDES)
MULTIPLE APC-8 PALLET POOL W/WORK SETTING STATION
FOUR FACE CONTROL (MACHINE FOUR DIFFERENT PARTS ON ONE PALLET)
ADDITIONAL REG. PRGRAMS 400
MACRO B PROGRAMMING
CUSTOM MARCO VARIABLE 600
HELICAL INTERPOLATION
INCH/METRIC CONVERSION
TOOL OFFSET MEMORY C
ADDITIONAL 48 FIXTURE OFFSETS
FULL ENCLOSURES
ALL AVAILABLE MANUALS
TOMBSTONES 3 AND 4 SIDED
