HAAS VF-2B YT

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
MACHINING CENTERS, VERTICAL
Manufacturer:
HAAS
Model:
VF 2YBT
Year:
2006
Stock #:
5448
Status:
For Sale

Description

WELL MAINTAINED HAAS VF 2YBT VERTICAL MACHINING CENTER HAS TRAVELS OF 30 X 20 X 20, 2 SPEED GEAR BOX 300 PSI COOLANT THRU AND IS PRE-WIRED FOR A 4TH AXIS.

X Travel30"762 mm
Y Travel20"508 mm
Z Travel20"508 mm
Spindle Speed7,500 RPM7500 rpm
Tool Capacity (ATC)2424
Table Size (W)36"914.4 mm
Table Size (L)18"457.2 mm
Main Spindle Motor30 hp
Spindle TaperCAT 40CAT 40
Spindle Nose To Table Top4" - 24"4" - 24"
Coolant ThruYesYes
Coolant Thru High PressureYesYes
Hi Pressure Coolant System300 psi
ControlCNC (HAAS)CNC (HAAS)

SPECIFICATIONS:
TABLE SIZE         36” X 18”
X-AXIS TRAVELS     30”
Y-AXIS TRAVELS     20”
Z-AXIS TRAVELS     20”
SPINDLE NOSE TO
        TABLE TOP  4” - 24”
SPINDLE SPEED      7,500 RPM
SPINDLE TAPER      CAT40
SPINDLE MOTOR      30 H.P. / AC DRIVES
TOOL CHANGER/ SIDE MOUNT  24 + 1 POSITIONS

HAAS CNC CONTROL
2-SPEED GEAR BOX
REMOTE JOG HANDLE
CHIP AUGER
THRU SPINDLE COOLANT (300 PSI) / PROGRAMMABLE COOLANT
4TH AXIS PRE-WIRE

CONTROL OPTIONS INCLUDE: SPINDLE ORIENTATION, ROTATION & SCALING, INTUITIVE
PROGRAMMING SYSTEM, MACROS, ETHERNET & HARD DRIVE, HI-INTENSITY LIGHTING,
16 MB MEMORY, AUX. FILTER, INTERNAL HIGH VOLTAGE TRANSFORMER.
