MAZAK AJV 50/120

SPECIFICATIONS:
TABLE SIZE 39.52" X 118.11"
TABLE TRAVEL X - AXIS 125.98"
Y - AXIS 45.12"
Z - AXIS 20"
DISTANCE FROM SPINDLE NOSE TO TABLE TOP 16.87"- 36.87"
DISTANCE BETWEEN COLUMNS 49.05"
TABLE LOAD CAPACITY 8,800 LBS.
RAPID TRAVERSE RATES 945 IPM (X) 945 (Y)
708 Z, IPM
CUTTING FEED RATES .04 - 196.8 IPM
SPINDLE NOSE #50 TAPER
SPINDLE SPEED 5000 RPM
TOOL MAGAZINE 60 ATC
MAX TOOL DIA. WHEN ADJACENT EMPTY 7.48"
MAX TOOL LENGTH 18.3"
MAX TOOL WEIGHT 33 LBS.
MAIN MOTOR 35 HP AC
MACHINE WEIGHT 55,200 LBS.
