MAZAK VTC 16A
Have one to sell?
ConditionUsed
1 available
THIS VTC 16A HAS TRAVELS OF 22 X 16 X 20, A CAT 40/ 8000 RPM SPINDLE AND PART PROBE.
SPECIFICATIONS:
X AXIS TRAVEL 22.05
Y AXIS TRAVEL 16.14
Z AXIS TRAVEL 20.08
TABLE SIZE 35.4 X 16.14"
MAX. TABLE LOAD 1,000 LBS.
SPINDLE NOSE TO TABLE 4" - 24.4"
SPINDLE MOTOR 15 HP
SPINDLE SPEEDS 8,000 RPM
SPINDLE TAPER CT 40
ATC 24
X & Y RAPIDS 787 IPM
Z AXIS RAPIDS 590 IPM
MACHINE DIMENSIONS (APP) 102.4" X 97.3 X 106"
MACHINE WEIGHT (APPROX) 8,800 LBS.
MAZATROL FUSION 640M
AC SERVO MOTORS
MAZAK MONITORING B MP 12
AUTO TOOL LENGTH MEASUREMENT
CHIP CONVEYOR INVERTER SIDE DISCHARGE
THIS VTC 16A HAS TRAVELS OF 22 X 16 X 20, A CAT 40/ 8000 RPM SPINDLE AND PART PROBE.
Imperial
| X Travel | 22.05" |
| Y Travel | 16.14" |
| Z Travel | 20.08" |
| Spindle Speed | 8000 rpm |
| Tool Capacity (ATC) | 24 |
| Table Size (W) | 35.4" |
| Table Size (L) | 16.14" |
| Main Spindle Motor | 15 hp |
| Spindle Taper | CAT 40 |
| Spindle Nose To Table Top | 4" - 24.4" |
| Control | CNC (MAZATROL FUSION 640M) |
| Dimensions | 102.4" X 97.3 X 106" |
| Weight | 8,800 LBS |
SPECIFICATIONS:
X AXIS TRAVEL 22.05
Y AXIS TRAVEL 16.14
Z AXIS TRAVEL 20.08
TABLE SIZE 35.4 X 16.14"
MAX. TABLE LOAD 1,000 LBS.
SPINDLE NOSE TO TABLE 4" - 24.4"
SPINDLE MOTOR 15 HP
SPINDLE SPEEDS 8,000 RPM
SPINDLE TAPER CT 40
ATC 24
X & Y RAPIDS 787 IPM
Z AXIS RAPIDS 590 IPM
MACHINE DIMENSIONS (APP) 102.4" X 97.3 X 106"
MACHINE WEIGHT (APPROX) 8,800 LBS.
MAZATROL FUSION 640M
AC SERVO MOTORS
MAZAK MONITORING B MP 12
AUTO TOOL LENGTH MEASUREMENT
CHIP CONVEYOR INVERTER SIDE DISCHARGE
