MAZAK VTC 800/30SR /5 AXIS VERTICAL MACHINING CENTER

MAZAK VTC 800/30SR /5 AXIS VERTICAL MACHINING CENTER

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
MACHINING CENTERS, VERTICAL
Manufacturer:
MAZAK
Model:
VTC 800/30SR
Year:
2019
Stock #:
5724
Status:
For Sale
Serial #:
299925

Description

2019 MAZAK VTC 800/ 30SR VERTICAL MACHINING CENTER MATRIX 2 CONTROL DUAL PROBING KIT - RMP600/RTS-AA SIMULTANEOUS 5 AXIS (G43.4), 40 TAPER WITH TRAVELS OF 118 X 31.5 X 28.35.

X Travel118.1"2,999.7 mm
Y Travel31.5"800.1 mm
Z Travel28.35"720.09 mm
Spindle Speed18,000 RPM18000 rpm
Tool Capacity (ATC)3030
Table Size (W)137.8"3,500.1 mm
Table Size (L)32.28"819.91 mm
Main Spindle Motor46.9 hp
Spindle TaperCAT 40CAT 40
4th Axis Rotary Table Size12.2"309.88 mm
5 Axis Programmable Axis'sFull 5 Axis's ContouringFull 5 Axis's Contouring
Coolant Thru High PressureYesYes
Hi Pressure Coolant System213 psi
Part ProbeYesYes
Tool Probe/Auto Tool Length MeasurementYesYes
ControlCNC (MATRIX 2 CONTROL)CNC (MATRIX 2 CONTROL)

SPECIFICATIONS:
TABLE RIGHT/LEFT                137.800"
TABLE LONGITUDINAL              32.280"
SPINDLE SPINDLE TAPER           40
MAXIMUM SPEED                   18000 RPM
MOTOR OUTPUT (30 MINUTE RATING) 46.9 HP / 35 KW
NUMBER OF TOOLS                 30
X AXIS TRAVEL                   118.10"
Y AXIS TRAVEL                   31.50"
Z AXIS TRAVEL                   28.35"

MATRIX 2 CONTROL
DUAL PROBING KIT - RMP600/RTS-AA
W/ EIA INSPECTION PLUS
G00 SLOPE CONSTANT
5 AXIS SPLINE INTERPOLATION (G61.2)1
SHAPE COMP FOR ROTARY AXIS (G61.1)
TOOL TIP POINT CONTROL
SIMULTANEOUS 5 AXIS (G43.4)
CYLINDRICAL INTERPOLATION
MAZAK MR-320RAM01 NC ROTARY TABLE PKG
12.2" 3 JAW MAN CHUCK SC-12T
KITAGAWA TS-320 TAILSTOCK FOR MAZAK MR-320 TABLE
213 HI-PRESSURE COOLANT THRU SPINDLE
