MORI SEIKI MV-55/50 VERTICAL MACHINING CENTER

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
MACHINING CENTERS, VERTICAL
Manufacturer:
MORI SEIKI
Model:
MV 55
Year:
1997
Stock #:
4078
Status:
For Sale

Description

THE MORI SEIKI MV-55/50 VERTICAL HAS A BT 50/ 4000 RPM SPINDLE, 40 X 20 X 20 TRAVELS, 30 STATION ATC AND A MORI MSC 516 CNC CONTROL.

X Travel41.3"1,049 mm
Y Travel21.7"551.18 mm
Z Travel22"558.8 mm
Spindle Speed4,000 RPM4000 rpm
Tool Capacity (ATC)3030
Table Size (W)55"1,397 mm
Table Size (L)21.6"548.64 mm
Main Spindle Motor15 hp
Spindle TaperBT 50BT 50
Spindle Nose To Table Top7.9 - 29.9”7.9 - 29.9”
Tool Probe/Auto Tool Length MeasurementYesYes
ControlCNC (MORI MSC516)CNC (MORI MSC516)
Dimensions142" X 197" X 124"142" X 197" X 124"
Weight22,000 LBS22,000 LBS

SPECIFICATIONS:
TABLE WORKING SURFACE 55" X 21.6"
TABLE LOAD CAPACITY 3300 LBS
LONGITUDINAL TRAVEL (X-AXIS) 41.3"
CROSS TRAVEL (Y-AXIS) 21.7"
VERTICAL TRAVEL (Z-AXIS) 22"
RAPID TRAVERSE RATE 745
TOOL STORAGE CAPA 30
SPINDLE HORSEPOWER 15HP
SPINDLE SPEED RANGE 40-4000
RPM SPINDLE TAPER BT50
APPROXIMATE MACHINE DIMENSIONS 142" X 197
APPROXIMATE MACHINE HEIGHT 124"
APPROXIMATE MACHINE WEIGHT 22,000 LBS

MORI MSC516 CNC CONTROL
30 STATION AUTOMATIC TOOL CHANGER
HEAVY DUTY 50
TAPER SPINDLE
AC SPINDLE AND AXIS DRIVES
MULTIPLE PART PROGRAM STORAGE
PROGRAMMABLE OFFSETS
RS232 DATA LINE
COOLANT SYSTEM
SPINDLE PROBE
