TOSHIBA VMC 85 4 AXIS VERTICAL MACHINING CENTER

SPECIFICATIONS:
TABLE SIZE 94.2" X 31.5"
TABLE TRAVEL X - AXIS 78.6"
Y - AXIS 33.5"
Z - AXIS 27.5"
DISTANCE FROM SPINDLE NOSE TO TABLE TOP 9.8" - 37.4"
TABLE LOAD CAPACITY 8,600 LBS.
SPINDLE NOSE CAT # 50
SPINDLE SPEED 20-4500 RPM
NUMBER OF GEAR RANGES 2
MAX SPINDLE TORQUE 723 FT.LBS.@ 214 RPM
TOOL MAGAZINE 40 ATC
MAX TOOL DIA. 4.3"/7.9"
MAX TOOL WEIGHT 33 LBS.
MAX.TOOL LENGTH 17.7"
MAIN MOTOR 35/25 HP AC
MACHINE WEIGHT 40,600 LBS.
