DMG MORI NZX 2000/800SY TWIN SPINDLE, TWIN TURRET LATHE
Have one to sell?
ConditionUsed
1 available
THIS 2016 NZX 2000/ 800SY HAS 2 - 16 STATION TURRETS, TWIN SPINDLES WITH 8" CHUCKS, 300 PSI COOLANT THRU, HOBBING, MAPPS CONVERSATIONAL PROGRAMMING AND A BOAT LOAD OF TOOLING!
SPECIFICATIONS:
SWING OVER BED 31.5"
TURNING DIAMETER 12.5"
TURNING LENGTH 31.8"
DISTANCE BETWEEN SPINDLES 44.1"
CHUCK SIZE 1, 2 8", 8"
SPINDLE NOSE 1, 2 A2-6, A2-6
BAR CAPACITY 1, 2 2.5"
SPINDLE SPEEDS 1, 2 5000, 5000 RPM
SPINDLE HORSEPOWER 1, 2 34.7, 34.7 HP HI TORQUE
X - AXIS TRAVEL X1, X2, X3 8.3", 8.3"
Z - AXIS TRAVEL Z1, Z2, Z3 31.9", 31.9"
Y - AXIS TRAVEL Y1, Y2, Y3 4.3" UPPER
C - AXIS INDEXING 1, 2 .001, .001 DEGREE
W - AXIS TRAVEL SUB SPINDLE 34.3"
RAPID TRAVERSE RATES X1, X2 1181, 1181 IPM
RAPID TRAVERSE RATES Z1, Z2 1968, 1968 IPM
RAPID TRAVERSE RATES Y1, Y2 787 IPM
TURRET TOOL POSITIONS 1, 2 16, 16 STATION
TURRET ROTARY TOOL SPEEDS 12,000 RPM
TURRET ROTARY TOOL HORSE POWER 10 HP
MACHINE WEIGHT 18,480 LBS.
FANUC 31IB CNC CONTROL
MAPPS CONVERSATIONAL PROGRAMING
(2) 300PSI HIGH PRESSURE COOLANT SYSTEMS
(2) HAINBUCH SPANNTOP NOVA 65 COLLET CHUCKS
(2) KITAGAWA BB 208 3 JAW HYDRAULIC CHUCKS
(2) TOOL SETTERS
12,000 RPM ROTARY TOOL SPEED UPPER AND LOWER TURRET
34 HP HI TORQUE OPTION
ALL AVAILABLE ROTARY TOOLING
ALL AVAILABLE STATIC TOOL HOLDERS
CHIP CONVEYOR
COOLANT THRU MILLING HEAD
HOBBING SOFTWARE ON MAIN SPINDLE
IEMCA KID 80 SHORT MAGAZINE BAR FEED
MAPPS CONVERSATIONAL PROGRAMING
OVERHEAD PARTS CATCHER AND PARTS CONVEYOR
PARTS CONVEYOR
RENISHAW TOOL PROBES
THIS 2016 NZX 2000/ 800SY HAS 2 - 16 STATION TURRETS, TWIN SPINDLES WITH 8" CHUCKS, 300 PSI COOLANT THRU, HOBBING, MAPPS CONVERSATIONAL PROGRAMMING AND A BOAT LOAD OF TOOLING!
Imperial
| Maximum Swing | 31.5" |
| Max Turning Diameter | 12.5" |
| Main Spindle Bore/Max Bar Capacity | 2.99/ 2.5 |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Cutting Length | 31.8" |
| Distance Between Spindles | 44.1" |
| X-Axis Travel (X1, X2, X3) | 8.3/ 8.3 |
| Z-Axis Travel (Z1, Z2, Z3) | 31.9/ 31.9 |
| Y-Axis Travel (Y1, Y2, Y3) | 4.3 UPPER |
| C-Axis Indexing (1, 2) | .001/ .001 |
| W-Axis Travel Sub Spindle | 34.3 in |
| Main Spindle Chuck Size | 8 mm |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 2.99" |
| Main Spindle Maximum Bar Work | 2.5" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 34.7 |
| Sub Spindle/2nd Spindle Chuck Size | 8 |
| Sub Spindle/2nd Spindle Bore Size | 2.99 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 34.7 |
| Number of Turrets | 2 |
| Turret Tool Positions 1, 2 | 16 |
| Turret Rotary Tool Spindle Speed 1, 2 | 12000 |
| Turret Rotary Tool Horse Power 1, 2 | 10 |
| Bar Feed | Yes |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| Tool Eye Automatic Front Spindle | No |
| Tool Eye Automatic Second Spindle | No |
| Tool Eye Measurement Upper Turret | Yes |
| Tool Eye Measurement Lower Turret | Yes |
| Coolant Thru Milling Head | Yes |
| High Pressure Coolant System (PSI) | 300 |
| Number of Available Live Tool Holders | 0 |
| Control | CNC (FANUC 31IB) |
| Weight | 18,480 LBS |
SPECIFICATIONS:
SWING OVER BED 31.5"
TURNING DIAMETER 12.5"
TURNING LENGTH 31.8"
DISTANCE BETWEEN SPINDLES 44.1"
CHUCK SIZE 1, 2 8", 8"
SPINDLE NOSE 1, 2 A2-6, A2-6
BAR CAPACITY 1, 2 2.5"
SPINDLE SPEEDS 1, 2 5000, 5000 RPM
SPINDLE HORSEPOWER 1, 2 34.7, 34.7 HP HI TORQUE
X - AXIS TRAVEL X1, X2, X3 8.3", 8.3"
Z - AXIS TRAVEL Z1, Z2, Z3 31.9", 31.9"
Y - AXIS TRAVEL Y1, Y2, Y3 4.3" UPPER
C - AXIS INDEXING 1, 2 .001, .001 DEGREE
W - AXIS TRAVEL SUB SPINDLE 34.3"
RAPID TRAVERSE RATES X1, X2 1181, 1181 IPM
RAPID TRAVERSE RATES Z1, Z2 1968, 1968 IPM
RAPID TRAVERSE RATES Y1, Y2 787 IPM
TURRET TOOL POSITIONS 1, 2 16, 16 STATION
TURRET ROTARY TOOL SPEEDS 12,000 RPM
TURRET ROTARY TOOL HORSE POWER 10 HP
MACHINE WEIGHT 18,480 LBS.
FANUC 31IB CNC CONTROL
MAPPS CONVERSATIONAL PROGRAMING
(2) 300PSI HIGH PRESSURE COOLANT SYSTEMS
(2) HAINBUCH SPANNTOP NOVA 65 COLLET CHUCKS
(2) KITAGAWA BB 208 3 JAW HYDRAULIC CHUCKS
(2) TOOL SETTERS
12,000 RPM ROTARY TOOL SPEED UPPER AND LOWER TURRET
34 HP HI TORQUE OPTION
ALL AVAILABLE ROTARY TOOLING
ALL AVAILABLE STATIC TOOL HOLDERS
CHIP CONVEYOR
COOLANT THRU MILLING HEAD
HOBBING SOFTWARE ON MAIN SPINDLE
IEMCA KID 80 SHORT MAGAZINE BAR FEED
MAPPS CONVERSATIONAL PROGRAMING
OVERHEAD PARTS CATCHER AND PARTS CONVEYOR
PARTS CONVEYOR
RENISHAW TOOL PROBES
