MAZAK VCS 530C/ 4 AXIS
MACHINING CENTERS, VERTICAL
THIS 2012 VCS 530C COMES WITH A 4TH AXIS & 8" CHUCK, SMART CONTROL, CAT 40, 12000 RPM AND COOLANT THRU SPINDLE.
| X Travel | 41.3" |
| Y Travel | 20.8" |
| Z Travel | 20.8" |
| Spindle Speed | 12000 rpm |
| Tool Capacity (ATC) | 30 |
| Table Size (W) | 21.6" |
| Table Size (L) | 51.2" |
| Main Spindle Motor | 25 hp |
| Spindle Taper | CAT 40 |
| 4 Axis Table Rotation | .001 Degree Positioning Only 360000 Degrees |
| 4th Axis Rotary Table Size | 8" |
| Coolant Thru | Yes |
| Part Probe | Yes |
| Tool Probe/Auto Tool Length Measurement | Yes |
| Control | CNC (MAZATROL SMART) |
| Dimensions | 120" x 120" x 112" |
| Weight | 15,180 Lbs |
MAZATROL SMART CONTROL
10.4" COLOR LCD
USB I/F (1-PORT)
COMPACT FLASH READER
EIA/ISO CODE INPUT FUNCTION
ADDITIONAL EIA/ISO FUNCTIONS
ABSOLUTE ENCODER SYS N/A WITH S/F-3AX
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
MAZAK HR-200RAM01 NC ROTARY TABLE PACKAGE $15,300.00 1
KITAGAWA TS-200 TAILSTOCK WITH MAZAK MR-160 & MR-200
$2,000.00
CHIP CONVEYOR LEFT (HIHGE/fOR STEEL)
$1,1788.88
RENISHAW OTS-RA OPTICAL TOOL
SETTER INCLUDING PREP FOR MMSB
$4,600.08
SYNCHRONIZED TAPPING
618.08
DISTRIBUTOR SUPPLIED ITEMS
$7,500.00
30 TOOL MAGAZINE
MAIN SPINDLE HOTOR AC18.5KW(25HP)
2 SPINDLE SPEED 12000 RPH
Y AXIS TRAVEL 20.86"
COMPLETE COOLANT SYSTEH
(STD FLOOOD 64 PSI)
TOTAL FULL COVER
ROLLER GUIDE
WORK LIGHT (LED)
POWER TRANSFORMER FOR NORTH AMERICAN MRKT
RELOCATION DEVICE
