*SOLD* MAZAK QTN 250MSY WITH BARFEEDER *SOLD*
Have one to sell?
ConditionUsed
1 available
THIS 2018 MAZAK QTN 250MSY HAS THE NEW SMOOTH G CONTROL, ROYAL A2-8 & A2-5 Q6-65 COLLET CHUCKS, PARTS CATCHER, BARFEEDER, COOLANT THRU SPINDLE, LIVE AND STATIC TOOLING INCLUDED - SEE LIST UNDER EQUIPPED WITH.
X AXIS TRAVELS 9"
Y AXIS TRAVELS 4"
Z AXIS TRAVELS 22.75"
MAIN SPINDLE 4,000 RPM / 30 HP
MAX THRU 3.50 / BAR 3.00 / MAIN NOSE - A26
SUB SPINDLE 6,000 RPM / 15 HP
MAX THRU SUB NOSE 1.50 / / A25
TURRET 12 POSITION VDI
LENGTH 9'9" X 6'3" X 6'3"
WEIGHT 11,905 LBS
MAZATROL SMOOTH G CONTROL
6K RPM LIVE TOOL
SPINDLE ORIENTATION - ONE POS
SPINDLE ORIENTATION - MULTI POS
MAIN SPINDLE - ROYAL A2-8 QG-65 - COMPACT
SUB-SPINDLE - ROYAL A2-5 QG-65 - COMPACT
AUTOMATIC PARTS CATCHER
WORKPIECE CONVEYOR WITH STAND
AUTO POWER OFF
AUTO POWER ON/OFF & WARM-UP
STD BARFEED INTERFACE
AUTO FRONT DOOR OPEN/CLOSE (LH DOOR)
MIST COLLECTOR PREP
STD ROBOT INTERFACE
SMOOTH ENGRAVING
PECK CYCLE W LOAD DETECTION
8MB MEMORY (STD IS 2MB)
LNS QUICK-LOAD 80-S2 - ETHERNET
USB (1)
ETHERNET (1)
1K PSI COOLANT PREPARATION (STD)
TOOL MEASURE AUTOMATIC
240VAC STANDARD W MULTI-TAP TRANSFORMER
3-PUSHERS / 1-LINER
(SEE ADDITIONAL LINERS BELOW)
CONSEP 2000 CHIP CONVEYOR - HIGH LIFT 6-FOOT
REMOVES FINES TO 50 MICRON - THIS WORKS EXCELLENT, ZERO CHIPS IN
COOLANT TANK
COOLANT - 213 PSI / 16 GPM
CHUCK AIRBLAST
TURRET AIRBLAST
WORK PROBE SYSTEM
HARDCOPY MANUALS
SIGNAL TOWER 3-COLORS
MAZAK TOOLING ;
TURNING HOLDER - FORWARD - 2X
TURNING HOLDER - REVERSE - 1X
FACING HOLDER - 1X
CUT OFF HOLDER - 1X
BORING BAR HOLDER - 1.500 ID - 2X
TURNING HOLDER - 2ND PROCESS - 1X
BORING BAR HOLDER 2ND PROCESS - 1.000 ID - 1X
HD OFFSET V-TYPE MILLING HOLDER - 6,000 RPM - 1X
HD H-TYPE MILLING HOLDER - 6,000 RPM - 2X
BORING BAR SOCKET - 1.000 ID X1.500 OD - 1X
BORING BAR SOCKET - 1.250 ID X1.500 OD - 1X
HOOK SPANNER
EXSYS EPPINGER TOOLING ;
STATIC HOLDERS -
OD TURN SQ SHANK 1.00 HLDR DOUBLE Y-AXIS - LH/RH DOUBLE SIDE - 3X
OD TURN SQ SHANK 1.00 HLDR DOUBLE Y-AXIS - LH SIDE - 3X
LIVE HOLDERS -
AXIAL ER32 DOUBLE SIDE R/L (H-TYPE) - 2X
RADIAL / STRAIGHT ER32 LH OFFSET (V-TYPE) - 3X
DOUBLE SPANNER WRENCH (FOR ABOVE)
ER32 WRENCH FORM F - SW32
WTO TOOLING ;
AXIAL ER32 DOUBLE SIDE R/L (H-TYPE) - 1X
SPINDLE LINERS FOR MAZAK QT250 MSY
O/2.560 I.D. STEEL LINER (2.50 STK)
O/2.082 I.D. STEEL LINER (2.00 STK)
O/0.685 I.D. STEEL LINER (.875 STK)
O/1.810 I.D. STEEL LINER (1.750 STK)
O/ 0.810 I.D. STEEL LINER (0.750 STK)
THIS 2018 MAZAK QTN 250MSY HAS THE NEW SMOOTH G CONTROL, ROYAL A2-8 & A2-5 Q6-65 COLLET CHUCKS, PARTS CATCHER, BARFEEDER, COOLANT THRU SPINDLE, LIVE AND STATIC TOOLING INCLUDED - SEE LIST UNDER EQUIPPED WITH.
Imperial
| Maximum Swing | 26.5" |
| Max Turning Diameter | 14.75" |
| Main Spindle Bore/Max Bar Capacity | 3.44"/ 3" |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Cutting Length | 21.275" |
| X-Axis Travel (X1, X2, X3) | 9 |
| Z-Axis Travel (Z1, Z2, Z3) | 22.63 |
| Y-Axis Travel (Y1, Y2, Y3) | 9 |
| Main Spindle Chuck Size | 0" |
| Main Spindle Chuck Type | Collet |
| Main Spindle Bore Diameter | 3.44" |
| Main Spindle Maximum Bar Work | 3" |
| Main Spindle Speed | 4,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 30 |
| Sub Spindle/2nd Spindle Chuck Size | 0 |
| Sub Spindle/2nd Spindle Bore Size | 1.5 |
| Sub Spindle/2nd Spindle Chuck Type | Collet |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 15 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Type | VDI |
| Bar Feed | Yes |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| High Pressure Coolant System (PSI) | 213 |
| Control | CNC (MAZATROL SMOOTH G) |
| Dimensions | 9'9" X 6'3" X 6'3" |
| Weight | 11,905 LBS |
X AXIS TRAVELS 9"
Y AXIS TRAVELS 4"
Z AXIS TRAVELS 22.75"
MAIN SPINDLE 4,000 RPM / 30 HP
MAX THRU 3.50 / BAR 3.00 / MAIN NOSE - A26
SUB SPINDLE 6,000 RPM / 15 HP
MAX THRU SUB NOSE 1.50 / / A25
TURRET 12 POSITION VDI
LENGTH 9'9" X 6'3" X 6'3"
WEIGHT 11,905 LBS
MAZATROL SMOOTH G CONTROL
6K RPM LIVE TOOL
SPINDLE ORIENTATION - ONE POS
SPINDLE ORIENTATION - MULTI POS
MAIN SPINDLE - ROYAL A2-8 QG-65 - COMPACT
SUB-SPINDLE - ROYAL A2-5 QG-65 - COMPACT
AUTOMATIC PARTS CATCHER
WORKPIECE CONVEYOR WITH STAND
AUTO POWER OFF
AUTO POWER ON/OFF & WARM-UP
STD BARFEED INTERFACE
AUTO FRONT DOOR OPEN/CLOSE (LH DOOR)
MIST COLLECTOR PREP
STD ROBOT INTERFACE
SMOOTH ENGRAVING
PECK CYCLE W LOAD DETECTION
8MB MEMORY (STD IS 2MB)
LNS QUICK-LOAD 80-S2 - ETHERNET
USB (1)
ETHERNET (1)
1K PSI COOLANT PREPARATION (STD)
TOOL MEASURE AUTOMATIC
240VAC STANDARD W MULTI-TAP TRANSFORMER
3-PUSHERS / 1-LINER
(SEE ADDITIONAL LINERS BELOW)
CONSEP 2000 CHIP CONVEYOR - HIGH LIFT 6-FOOT
REMOVES FINES TO 50 MICRON - THIS WORKS EXCELLENT, ZERO CHIPS IN
COOLANT TANK
COOLANT - 213 PSI / 16 GPM
CHUCK AIRBLAST
TURRET AIRBLAST
WORK PROBE SYSTEM
HARDCOPY MANUALS
SIGNAL TOWER 3-COLORS
MAZAK TOOLING ;
TURNING HOLDER - FORWARD - 2X
TURNING HOLDER - REVERSE - 1X
FACING HOLDER - 1X
CUT OFF HOLDER - 1X
BORING BAR HOLDER - 1.500 ID - 2X
TURNING HOLDER - 2ND PROCESS - 1X
BORING BAR HOLDER 2ND PROCESS - 1.000 ID - 1X
HD OFFSET V-TYPE MILLING HOLDER - 6,000 RPM - 1X
HD H-TYPE MILLING HOLDER - 6,000 RPM - 2X
BORING BAR SOCKET - 1.000 ID X1.500 OD - 1X
BORING BAR SOCKET - 1.250 ID X1.500 OD - 1X
HOOK SPANNER
EXSYS EPPINGER TOOLING ;
STATIC HOLDERS -
OD TURN SQ SHANK 1.00 HLDR DOUBLE Y-AXIS - LH/RH DOUBLE SIDE - 3X
OD TURN SQ SHANK 1.00 HLDR DOUBLE Y-AXIS - LH SIDE - 3X
LIVE HOLDERS -
AXIAL ER32 DOUBLE SIDE R/L (H-TYPE) - 2X
RADIAL / STRAIGHT ER32 LH OFFSET (V-TYPE) - 3X
DOUBLE SPANNER WRENCH (FOR ABOVE)
ER32 WRENCH FORM F - SW32
WTO TOOLING ;
AXIAL ER32 DOUBLE SIDE R/L (H-TYPE) - 1X
SPINDLE LINERS FOR MAZAK QT250 MSY
O/2.560 I.D. STEEL LINER (2.50 STK)
O/2.082 I.D. STEEL LINER (2.00 STK)
O/0.685 I.D. STEEL LINER (.875 STK)
O/1.810 I.D. STEEL LINER (1.750 STK)
O/ 0.810 I.D. STEEL LINER (0.750 STK)
