DOOSAN MX 1600ST LATHE WITH SUB-SPINDLE AND LOWER TURRET

DOOSAN MX 1600ST LATHE WITH SUB-SPINDLE AND LOWER TURRET

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
DOOSAN
Model:
PUMA MX 1600ST
Condition:
Excellent
Year:
2020
Stock #:
210102
Status:
For Sale

Description

THIS 2020 DOOSAN MX 1600ST HAS (2) ROYAL QG-65 COLLET CHUCKS AND INSTALLATION TOOLS, A TURBO CHIP CONVEYOR, 16 POSITION LOWER TURRET AND A GREAT ASSORTMENT OF TOOLS.
**ONLY 250 CUT HOURS!**

Maximum Swing26.77"679.96 mm
Max Turning Diameter13"330.2 mm
Main Spindle Bore/Max Bar Capacity2.44"/ 2.0"2.44"/ 2.0"
Tail Stock/Sub SpindleSub SpindleSub Spindle
Distance Between Centers35.4"899.16 mm
Maximum Cutting Length35.4"899.16 mm
X-Axis Travel (X1, X2, X3)17.717.7
Z-Axis Travel (Z1, Z2, Z3)36.836.8
Y-Axis Travel (Y1, Y2, Y3)+/- 3.4"+/- 3.4"
Main Spindle Chuck TypeColletCollet
Main Spindle Bore Diameter2.44"61.976 mm
Main Spindle Maximum Bar Work2"50.8 mm
Main Spindle Speed6,000 RPM6,000 RPM
Main Spindle Horsepower (CONT. /30 MINS)2020
Sub Spindle/2nd Spindle Chuck Size00
Sub Spindle/2nd Spindle Bore Size2.02.0
Sub Spindle/2nd Spindle Chuck TypeColletCollet
Sub Spindle/2nd Spindle Speed6,000 RPM6,000 RPM
Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS)2020
Turret Tool Positions 1, 21616
B-Axis Travel+/- 120DEG+/- 120DEG
B-Axis Milling Spindle Speed12,000 RPM12000 rpm
B-Axis Milling Spindle Horse Power1212
Chip ConveyorYesYes
ControlCNC (FANUC)CNC (FANUC)
Dimensions109" X 130" X 105.5"109" X 130" X 105.5"
Weight24,910 LBS24,910 LBS

FANUC CONTROL
RENISHAW RMI-Q RADIO RECEIVER AND MACHINE INTERFACE PACKAGE (15M)
REN-RMIQ-SW-1
RMP600-C5-DIA
MANUAL QG-65 COLLET INSTALLATION TOOL
(2) ROYAL QG-65 COMPACT QUICK CHANGE ACCU-LENGTH COLLET CHUCKS
TURBO SIDE DISCHARGE MH250 MICRON CHIP CONVEYOR WITH AIR HEADER, VARIABLE SPEED DRIVE AND M-CODE CAPABILITY.
