MAZAK QTN 350-II MY WITH MILLING AND Y AXIS
Have one to sell?
ConditionUsed
1 available
THIS 2014 QTN 350MY IS AN 80" MACHINE WITH LIVE TOOLING WITH MILLING ON TURET AND Y-AXIS, E-STOP, HYDRAULIC STEADY REST AND CHIP CONVEYOR.
MAZATROL MATRIX NEXUS 2
RE-THREAD FUNCTION
THREAD START COMPENSATION
E-STOP FOR CHIP CONVEYOR
HYDRAULIC STEADY REST 2.5" - 9.5"
LIVE TOOLING WITH MILLING ON TURRET
CHIP CONVEYOR
THIS 2014 QTN 350MY IS AN 80" MACHINE WITH LIVE TOOLING WITH MILLING ON TURET AND Y-AXIS, E-STOP, HYDRAULIC STEADY REST AND CHIP CONVEYOR.
Imperial
| Maximum Swing | 29.3" |
| Max Turning Diameter | 16.53" |
| Main Spindle Bore/Max Bar Capacity | 4.45" |
| Tail Stock/Sub Spindle | Tail Stock |
| Distance Between Centers | 80" |
| Maximum Cutting Length | 60.55" |
| X-Axis Travel (X1, X2, X3) | 10.23" |
| Z-Axis Travel (Z1, Z2, Z3) | 78.74" |
| Y-Axis Travel (Y1, Y2, Y3) | 3.93" |
| Main Spindle Chuck Size | 12" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 4.45" |
| Main Spindle Maximum Bar Work | 4" |
| Main Spindle Speed | 4,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 40 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 6000 |
| Steady Rest | Yes |
| Chip Conveyor | Yes |
| Control | CNC (MAZATROL MATRIX NEXUS 2) |
| Dimensions | 255" x 67" x 91" |
MAZATROL MATRIX NEXUS 2
RE-THREAD FUNCTION
THREAD START COMPENSATION
E-STOP FOR CHIP CONVEYOR
HYDRAULIC STEADY REST 2.5" - 9.5"
LIVE TOOLING WITH MILLING ON TURRET
CHIP CONVEYOR
