2018 DMG Mori NLX-2500SY/1250
Multi-Axis CNC Lathe with Lexair FB11-40 Full Bore Type Collet Chuck on main
Kitagawa 8” 3-Jaw Hydraulic Chuck
| Maximum Swing | 36.2" |
| Max Turning Diameter | 14.4" |
| Maximum Swing Over Cross Slide | 29.2" |
| Maximum Cutting Length | 49.4" |
| X-Axis Travel (X1, X2, X3) | 10.2” |
| Z-Axis Travel (Z1, Z2, Z3) | 53” |
| Y-Axis Travel (Y1, Y2, Y3) | +/-2.0” |
| W-Axis Travel Sub Spindle | 50.6 in |
| Main Spindle Chuck Size | 8" |
| Main Spindle Bore Diameter | 3.6" |
| Main Spindle Maximum Bar Work | 3.1" |
| Main Spindle Speed | 4,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 25/20 |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 15/10 |
| Number of Turrets | 1 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 10000 |
| Turret Rotary Tool Horse Power 1, 2 | 7.55 |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| Chip Conveyor | Side |
| Tool Eye Automatic Front Spindle | Yes |
| Rapid Traverse, X-Axis | 1181 |
| Rapid Traverse, Y-Axis | 393.7 |
| Rapid Traverse, Z-Axis | 1181 |
| Control | CNC (M730UM) |
Swing Over Bed 36.2”
Swing Over Cross Slide 29.2”
Max Turning Diameter 14.4”
Standard Turning Diameter 10.6”
Max. Turning Length 49.4”
Bar Work Capacity 3.1”
X-Axis Travel 10.2”
Y-Axis Travel +/-2.0”
Z-Axis Travel 53”
B-Axis (spindle 2) 50.6”
Spindle 1
Max Spindle Speed 4000 RPM
Motor 25/20 HP
Spindle Nose A2-8
Through-Spindle Hole Diameter 3.6”
Spindle 2
Max Spindle Speed 6000 RPM
Motor 15/10 HP
Spindle Nose A2-5
No. of Tool Sations 12
Max Rotary Tool Spindle Speed 10,000 RPM
Rotary Motor 7.5/5HP
Rapid Traverse Rate XZB: 1181 IPM / Y: 393.7 IPM
Floor Space with
Chip Conveyor 198” x 87” x 89”
Weight 17,000 lbs est.
Control M730UM with Celos
Sub Spindle
Milling
Y-Axis
Tool Prestter
Chip Conveyor Interface Right Discharge
Parts Catcher
Lexair FB11-40 Full Bore Type Collet Chuck on main
Kitagawa 8” 3-Jaw Hydraulic Chuck
