HAAS ST-40 LATHE WITH MILLING, AND STEADY REST BASE

Have one to sell?

ConditionUsed

Quantity

1 available

Have one to sell?

Overview

Type:

CNC LATHES MULTI AXIS

Manufacturer:

Model:

ST 40

Condition:

Good

Year:

2013

Stock #:

210185

Status:

For Sale

HAAS ST-40 LATHE WITH MILLING AND STEADY REST BASE.COMING OUT OF SEMICONDUCTOR FACILITY.BEAUTIFUL MACHINE

ImperialMetric

Maximum Swing	34.5"	876.3 mm
Max Turning Diameter	25.5"	647.7 mm
Main Spindle Bore/Max Bar Capacity	4.4"/ 4.0	4.4"/ 4.0
Tail Stock/Sub Spindle	TAILSTOCK	TAILSTOCK
Maximum Swing Over Cross Slide	25.5"	647.7 mm
Maximum Cutting Length	44"	1,117.6 mm
X-Axis Travel (X1, X2, X3)	17.0	17.0
Z-Axis Travel (Z1, Z2, Z3)	40	40
C-Axis Indexing (1, 2)	.001	.001
Main Spindle Chuck Size	15"	381 mm
Main Spindle Chuck Type	Hydraulic	Hydraulic
Main Spindle Speed	2,400 RPM	2,400 RPM
Main Spindle Horsepower (CONT. /30 MINS)	40	40
Turret Tool Positions 1, 2	12	12
Turret Rotary Tool Spindle Speed 1, 2	4000	4000
Chip Conveyor	Yes	Yes
Tool Eye Automatic Front Spindle	Yes	Yes
Rapid Traverse, X-Axis	710	710
Rapid Traverse, Z-Axis	710	710
Control	CNC (HAAS)	CNC (HAAS)

HAAS CNC CONTROL
TOOL PRE-SETTER
TAILSTOCK
15" HYDRAULIC CHUCK
FULL C-AXIS MILLING
STEADY REST BASE
CHIP CONVEYOR
