**PREPPED AND LOADED** MAZAK INTEGREX I-500S-2500U

**PREPPED AND LOADED** MAZAK INTEGREX I-500S-2500U

Have one to sell?
(480) 423-9045
Sales@QMSused.com
ConditionUsed
1 available
Have one to sell?

Overview

Type:
CNC LATHES MULTI AXIS
Manufacturer:
MAZAK
Model:
INTEGREX I-500S-2500U
Year:
2019
Stock #:
210195
Status:
For Sale

Description

THIS 2019 MAZAK INTEGREX I-500S-2500U MAZATROL SMOOTH X CONTROL, SMW AUTOBLOK KNCS-NB 325/104 (2), 5 AXIS MACHINING PACKAGE FOR SMOOTH X, AIR THRU SPINDLE, MAZAK SUPERFLOW 1000 PSI CTS, SMW SLUX Z-4 STEADY REST (1.18"-9.65" CAP) WORK MEASURING SYSTEM AND LP-2 TOOL PROBE SYSTEM..PURCHASED.**PREPPED AND LOADED**

Maximum Swing27.56"700.02 mm
Max Turning Diameter27.56"700.02 mm
Main Spindle Bore/Max Bar Capacity4.4"/ 4"4.4"/ 4"
Tail Stock/Sub SpindleSub SpindleSub Spindle
Maximum Cutting Length102.13"2,594.1 mm
X-Axis Travel (X1, X2, X3)33.2733.27
Z-Axis Travel (Z1, Z2, Z3)104.72104.72
Y-Axis Travel (Y1, Y2, Y3)16.9316.93
C-Axis Indexing (1, 2)0.00010.0001
Main Spindle Chuck Size12"304.8 mm
Main Spindle Chuck TypeHydraulicHydraulic
Main Spindle Bore Diameter4.4"111.76 mm
Main Spindle Maximum Bar Work4"101.6 mm
Main Spindle Speed3,300 RPM3,300 RPM
Sub Spindle/2nd Spindle Chuck Size1212
Sub Spindle/2nd Spindle Bore Size4.4"4.4"
Sub Spindle/2nd Spindle Speed3,300 RPM3,300 RPM
ATC Magazine Capacity3636
Turret Rotary Tool Spindle Speed 1, 21200012000
ControlCNC (MAZATROL SmoothX)CNC (MAZATROL SmoothX)

Specifications (subject to buyer verification):
Spindle Bore Diameter (First & Second Spindle): 4.4”
Spindle Speeds (First & Second): 3,300 RPM
Contouring: C-2 Axis 0.0001 Deg for Second Spindle
Tool Magazine Capacity: 36 Capto C8
Bed length: 100”
X-Axis: 33.27”
Y-Axis: 16.93”
Z-Axis: 102.3”
Horsepower: 32
RPM: 12,000
Pallet Size: 27.56” x 102.13”

SMW AUTOBLOK KNCS-NB 325/104 (2)
AUTO PECKING CYCLE WITH LOAD DETECTION
RE-THREADING
THREAD START POINT COMPENSATION
PREPARATION FOR MULTI & FLASH TOOL SYSTEM
TOOL CUTTING POINT CONTROL
TOOL LENGTH COMP IN TOOL AXIS DIRECTION
5-AXIS MACHINING PACKAGE FOR SMOOTHX
SECOND SPINDLE, SIMULTANEOUS 5 AXES SOFTWARE
MAXIMUM PROGRAM SIZE: 32MB
ROBOT INTERFACE
MT CONNECT ADAPTER SOFTWARE
SMOOTH PLC ALARM ADVISOR
SMOOTH SET & INSPECTION
COOLANT FLUSHING MAIN & SECOND SPINDLE
AIR THRU SPINDLE
PREP FOR VISUAL TOOL ID?DATA MANAGEMENT FOR CAPTO MAGAZINE
CHIP CONVEYOR (SIDE DISPOSAL)
AUTOMATIC FRONT DOOR OPEN/CLOSE
OVERLOAD DETECTION SYSTEM
SIGNAL TOWER (THREE (3) COLOUR LIGHTS, SQUARE)
MIST COLLECTOR (GP2000)
PREP 70KG/1000 PSI SUPER FLOW COOLANT
MAZAK SUPER FLOW V8A VARIABLE HIGH PRESSURE COOLANT UNIT
QUICK COOLANT STOP SYSTEM
SHOWER COOLANT FOR FIRST & SECOND SPINDLE
PREPARATION FOR STEADY REST WITHOUT BRACKET (NC SERVO BASE)
SMW SLUX-Z-4 STEADY REST INSTALLED (1.18” – 9.65” CAP.)
WORK MEASURING SYSTEM
GLOBAL INDUSTRIAL SOLUTIONS LP-2 TOOL PROBE SYSTEM
