MORI SEIKI NL 2000SY/ 500 MULTI AXIS LATHE
Have one to sell?
ConditionUsed
1 available
Mori Seiki MSX-850 CNC Control
Parts Catcher
Barfeed Interface
Turbo Systems Chip Conveyor
Imperial
| Maximum Swing | 36.4" |
| Max Turning Diameter | 20" |
| Main Spindle Bore/Max Bar Capacity | 2.99"/ 2.5" |
| Tail Stock/Sub Spindle | SUB-SPINDLE |
| Maximum Swing Over Cross Slide | 29.7" |
| Distance Between Centers | 19.68" |
| X-Axis Travel (X1, X2, X3) | 10.2" |
| Z-Axis Travel (Z1, Z2, Z3) | 23.2" |
| Y-Axis Travel (Y1, Y2, Y3) | 3.9” <+- 2.0”> |
| Main Spindle Chuck Size | 8" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 2.99" |
| Main Spindle Maximum Bar Work | 2.5" |
| Main Spindle Speed | 5,000 RPM |
| Sub Spindle/2nd Spindle Chuck Size | 8 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Turret Tool Positions 1, 2 | 12 |
| B-Axis Milling Spindle Speed | 6000 rpm |
| Chip Conveyor | Yes |
| Control | CNC (Mori Seiki MSX-850) |
Mori Seiki MSX-850 CNC Control
Parts Catcher
Barfeed Interface
Turbo Systems Chip Conveyor
