DOOSAN LYNX 2100LSYB MULTI-AXIS LATHE
Have one to sell?
ConditionUsed
1 available
2018 DOOSAN LYNX 2100LSYB HAS A DOOSAN/ FANUC CONTROL, STATIC & LIVE TOOL HOLDER PACKAGE, MAIN SPINDLE CHUCK AND COLLET, SUB-SPINDLE CHUCK AND COLLET, BAR FEEDER AND CHIP CONVEYOR.
DOOSAN/ FANUC CONTROL
STATIC AND LIVE TOOL HOLDER PACKAGE
MAIN SPINDLE CHUCK AND COLLET NOSE
SUBSPINDLE CHUCK AND COLLET NOSE
*NO PERISHABLE TOOLING INCLUDED
2018 DOOSAN LYNX 2100LSYB HAS A DOOSAN/ FANUC CONTROL, STATIC & LIVE TOOL HOLDER PACKAGE, MAIN SPINDLE CHUCK AND COLLET, SUB-SPINDLE CHUCK AND COLLET, BAR FEEDER AND CHIP CONVEYOR.
Imperial
| Maximum Swing | 23.6" |
| Max Turning Diameter | 11.8" |
| Main Spindle Bore/Max Bar Capacity | 2.6 |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Cutting Length | 20" |
| X-Axis Travel (X1, X2, X3) | 22" |
| Z-Axis Travel (Z1, Z2, Z3) | 22" |
| Y-Axis Travel (Y1, Y2, Y3) | 4.1±2.1 |
| Main Spindle Chuck Size | 10" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Maximum Bar Work | 2.6" |
| Main Spindle Speed | 4,500 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 20 |
| Sub Spindle/2nd Spindle Chuck Size | 5 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 7.5 |
| Turret Rotary Tool Spindle Speed 1, 2 | 6000 |
| Bar Feed | Yes |
| Chip Conveyor | Yes |
| Control | CNC (DOOSAN FANUC i-SERIES) |
DOOSAN/ FANUC CONTROL
STATIC AND LIVE TOOL HOLDER PACKAGE
MAIN SPINDLE CHUCK AND COLLET NOSE
SUBSPINDLE CHUCK AND COLLET NOSE
*NO PERISHABLE TOOLING INCLUDED
