Overview

Type:
MACHINING CENTERS, HORIZONTAL
Manufacturer:
MAKINO
Model:
A-92
Condition:
Good
Year:
2011
Stock #:
210221
Status:
For Sale

Description

2011 MAKINO a92 HAS A PRO 5 CONTROL, PALLET SIZE: 39.4" X 31.5", 90 TOOL ATC, FULL B AXIS - 0.0001°, CAT 50 | 8,000 RPM | 50 HP | 90 ATC AND RENISHAW PROBING.

X-AXIS TRAVEL59.8"1,518.9 mm
Y-AXIS TRAVEL49.2"1,249.7 mm
Z-AXIS TRAVEL53.1"1,348.7 mm
SPINDLE TAPERCAT 50CAT 50
SPINDLE DRIVE MOTOR50 hp
SPINDLE SPEED8,000 RPM8000 rpm
MAX WORKPIECE SIZE59" X 59"59" X 59"
MAXIMUM WORKPIECE DIAMETER5,959"151,359 mm
TOOL CAPACITY (ATC)9090
NUMBER OF PALLETS22
PALLET SIZE31.5" X 39.4"31.5" X 39.4"
PALLET SIZE (W)31.5"800.1 mm
PALLET SIZE (L)39.4"1,000.8 mm
PALLET LOAD CAPACITY4400 lb
4 AXIS PALLET TABLE INDEXING.001.001
PART PROBEYESYES
TOOL PROBE/AUTO TOOL LENGTH MEASUREYesYes
HI-PRESSURE COOLANT SYSTEM300 psi
CHIP CONVEYORYesYes
ControlCNC (Makino Professional 5)CNC (Makino Professional 5)
Dimensions136 X 197 X 133136 X 197 X 133
Weight80,000 LBS80,000 LBS

MAKINO PROFESSIONAL 5 CNC CONTROL
COOLANT THROUGH SPINDLE - HIGH PRESSURE
CHIP CONVEYOR
COOLANT TANK
RENISHAW PROBING
CHIP BLASTER
SPINDLER CHILLER
AIR DRYER
