MAZAK QTN 200MS II -****SEE NEW PICTURES ****
Have one to sell?
ConditionUsed
1 available
THIS 2016 MAZAK QTN 200MS HAS MATRIX 2 CONTROL, 8" & 6" CHUCKS, BARFEED PREP, PARTS CATCHER, 2 LIVE, AND 2 STATIC TOOLS, AND A SIDE EXIT CHIP CONVEYOR. AND ONLY 1100 CUT HOURS!
SPECIFICATIONS:
SWING OVER BED 26.5"
TURNING DIAMETER, SHAFT DIAMETER 13.78"
MACHINING LENGTH 21.27"
DISTANCE BETWEEN SPINDLES 22.7"
CHUCK SIZE 1, 2 8", 6"
SPINDLE NOSE 1, 2 A2-6, A2-5
SPINDLE BORE DIAMETER 1, 2 2.99"
SPINDLE BAR CAPACITY 1, 2 2"
SPINDLE SPEEDS 1, 2 5000, 6000 RPM
SPINDLE HORSEPOWER 1, 2 35, 15 HP
X - AXIS TRAVEL 1, 2 9"
Z - AXIS TRAVEL 1, 2 21.28"
C - AXIS TRAVEL 1, 2 .001, .001 DEGREES
W - AXIS TRAVEL SUB SPINDLE 23"
RAPID TRAVERSE RATES X1, X2 1181 IPM
RAPID TRAVERSE RATES Z1, Z2 1229 IPM
RAPID TRAVERSE RATE W AXIS 826 IPM
TURRET CONFIGURATION 1, 2 12 STATIONS
TURRET ROTARY TOOL SPINDLE SPEED 1, 2 4500 RPM
TURRET ROTARY TOOL HORSE POWER 1, 2 7.5 HP
MACHINE WEIGHT 11,243 LBS.
MAZATROL MATRIX NEXUS 2 CONTROL
12.1" COLOR CD
EIA/ ISO INPUT FUNCTION
USER MACRO - 600 PAIRS
SEQUENCE NUMBER COMP STOP FUNCTION
LAN PORT
USB I/F (2-PORT)
CYLINDRICAL & POLAR COORDINATE
ROLLER GUIDE
ABSOLUTE POSITIONING
AUTOMATIC TOOL EYE
HIGH POWER COOLANT - 118 PSI/ 16 GPM
12 POSITION VDI TURRET
4500 RPM ROTARY TOOL SPEED
MILLING-SPINDLE SYNCHRONOUS TAPPING
C-AXIS 0.0001 - 1ST SPINDLE
1ST SPINDLE SPEED - 5000 RPM
SPINDLE BORE - 2.99"
KITAGAWA B-208A6 CHUCK WITH S-1552 CYCL - 2" CAP
AUTO CHUCK JAWS OPEN/ CLOSE
CHUCK OPEN/ CLOSE CONFIRM
2ND SPINDLE C-AXIS - .0001 DEGREE INCLUDING EIA INPUT FUNCTION
2ND SPINDLE MOTOR - 15HP
2ND SPINDLE BORE - 2.05"/ A2-5 NOSE/ 6000 RPM
KITAGAWA B-206A5 W/RNKP105-15 CLOSED CYL
CHUCK AIR BLAST - 2ND SPINDLE
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
HYDRAULIC PRESSURE INTERLOCK
MULTITAP TRANSFORMER
RELOCATION DEVICE
AUTOMATIC PARTS CATCHER (2.52" X 4.7" x 5.5 LBS)
PREPPED FOR LNS BARFEEDER
CHIP CONVEYOR - SIDE
2 LIVE/ 2 STATIC TOOLS
THIS 2016 MAZAK QTN 200MS HAS MATRIX 2 CONTROL, 8" & 6" CHUCKS, BARFEED PREP, PARTS CATCHER, 2 LIVE, AND 2 STATIC TOOLS, AND A SIDE EXIT CHIP CONVEYOR. AND ONLY 1100 CUT HOURS!
Imperial
| Maximum Swing | 26.5" |
| Max Turning Diameter | 13.78" |
| Main Spindle Bore/Max Bar Capacity | 2.99/ 2.0 |
| Tail Stock/Sub Spindle | Sub Spindle |
| Maximum Cutting Length | 21.27" |
| Distance Between Spindles | 22.7" |
| X-Axis Travel (X1, X2, X3) | 9 |
| Z-Axis Travel (Z1, Z2, Z3) | 21.28 |
| C-Axis Indexing (1, 2) | .001, .001 DEGREES |
| W-Axis Travel Sub Spindle | 23 in |
| Main Spindle Chuck Size | 8" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 2.99" |
| Main Spindle Maximum Bar Work | 2" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 35 |
| Sub Spindle/2nd Spindle Chuck Size | 6 |
| Sub Spindle/2nd Spindle Bore Size | 2.0 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 6,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 15 |
| Main & Sub Spindle Synchronization | No |
| Number of Turrets | 1 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 4500 |
| Turret Rotary Tool Horse Power 1, 2 | 7.0 |
| Bar Feed | Yes |
| Parts Catcher | Yes |
| Chip Conveyor | Yes |
| Milling Spindle Synchronous Tapping | Yes |
| Tool Eye Automatic Front Spindle | Yes |
| Tool Eye Automatic Second Spindle | Yes |
| High Pressure Coolant System (PSI) | 300 |
| Number of Available Live Tool Holders | 5 |
| Control | CNC (MAZATROL MATRIX NEXUS 2) |
| Weight | 11,243 LBS |
SPECIFICATIONS:
SWING OVER BED 26.5"
TURNING DIAMETER, SHAFT DIAMETER 13.78"
MACHINING LENGTH 21.27"
DISTANCE BETWEEN SPINDLES 22.7"
CHUCK SIZE 1, 2 8", 6"
SPINDLE NOSE 1, 2 A2-6, A2-5
SPINDLE BORE DIAMETER 1, 2 2.99"
SPINDLE BAR CAPACITY 1, 2 2"
SPINDLE SPEEDS 1, 2 5000, 6000 RPM
SPINDLE HORSEPOWER 1, 2 35, 15 HP
X - AXIS TRAVEL 1, 2 9"
Z - AXIS TRAVEL 1, 2 21.28"
C - AXIS TRAVEL 1, 2 .001, .001 DEGREES
W - AXIS TRAVEL SUB SPINDLE 23"
RAPID TRAVERSE RATES X1, X2 1181 IPM
RAPID TRAVERSE RATES Z1, Z2 1229 IPM
RAPID TRAVERSE RATE W AXIS 826 IPM
TURRET CONFIGURATION 1, 2 12 STATIONS
TURRET ROTARY TOOL SPINDLE SPEED 1, 2 4500 RPM
TURRET ROTARY TOOL HORSE POWER 1, 2 7.5 HP
MACHINE WEIGHT 11,243 LBS.
MAZATROL MATRIX NEXUS 2 CONTROL
12.1" COLOR CD
EIA/ ISO INPUT FUNCTION
USER MACRO - 600 PAIRS
SEQUENCE NUMBER COMP STOP FUNCTION
LAN PORT
USB I/F (2-PORT)
CYLINDRICAL & POLAR COORDINATE
ROLLER GUIDE
ABSOLUTE POSITIONING
AUTOMATIC TOOL EYE
HIGH POWER COOLANT - 118 PSI/ 16 GPM
12 POSITION VDI TURRET
4500 RPM ROTARY TOOL SPEED
MILLING-SPINDLE SYNCHRONOUS TAPPING
C-AXIS 0.0001 - 1ST SPINDLE
1ST SPINDLE SPEED - 5000 RPM
SPINDLE BORE - 2.99"
KITAGAWA B-208A6 CHUCK WITH S-1552 CYCL - 2" CAP
AUTO CHUCK JAWS OPEN/ CLOSE
CHUCK OPEN/ CLOSE CONFIRM
2ND SPINDLE C-AXIS - .0001 DEGREE INCLUDING EIA INPUT FUNCTION
2ND SPINDLE MOTOR - 15HP
2ND SPINDLE BORE - 2.05"/ A2-5 NOSE/ 6000 RPM
KITAGAWA B-206A5 W/RNKP105-15 CLOSED CYL
CHUCK AIR BLAST - 2ND SPINDLE
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
HYDRAULIC PRESSURE INTERLOCK
MULTITAP TRANSFORMER
RELOCATION DEVICE
AUTOMATIC PARTS CATCHER (2.52" X 4.7" x 5.5 LBS)
PREPPED FOR LNS BARFEEDER
CHIP CONVEYOR - SIDE
2 LIVE/ 2 STATIC TOOLS
