DMG MORI SEIKI NZX-2000/800STY3 - 9 AXIS CNC TWIN SPINDLE TURNING CENTER LOW HOURS
Have one to sell?
ConditionUsed
1 available
THIS 2016 NZX 2000/800STY3 HAS A CELOS (F31iB) CONTROL, TWIN SPINDLES, (3) TURRETS WITH Y-AXIS, 2 - 10" CHUCKS, 2 MICRO CENTRIC MBS COLLET CHUCKS, CHIP BLASTER HIGH PRESSURE COOLANT SYSTEM, C-AXIS HIGH PRECISION INDEXING, HOBBIN & MORE.
CELOS (F31IB) CNC CONTROL
21.5" COLOR ERGOLINE TOUCH TFT
TWIN SPINDLES
(3) TURRETS WITH Y-AXIS
12,000 RPM MILLING SPEED
(2) MICRO CENTRIC MBS 200 COLLET CHUCKS
CHIP BLASTER/CHIP CHILLER HIGH PRESSURE COOLANT SYSTEM
COOLANT GUN
CHUCK TOP COOLANT
AIR PURGE (LEFT AND RIGHT SPINDLE)
AIR BLOW FOR TOOL TIP (T1, T2, AND T3)
X-AXIS DIRECT SCALE FEEDBACK (X1, X2, X3)
CHIP CONVEYOR (SIDE EXIT SCRAPER TYPE)
ETHERNET CAPABILITY
AUTOMATIC DOOR
TOOL PRESETTER (LEFT AND RIGHT SPINDLE)
(5) EXTERNAL M-CODES
3-D COORDINATE CONVERSION
TOOL RETRACT AND RECOVER
HOBBING FUNCTION
X-AXIS DIRECTION JIS / ISO
C-AXIS HIGH-PRECISION INDEXING
4 COLOR SIGNAL LIGHT
BUILT IN WORK LIGHT
17,110 POWER ON TIME
663 OPERATION TIME HEAD 1
1907 OPERATION TIME HEAD 2
1662 OPERATION TIME HEAD 3
609 CUTTING TIME HEAD 1
375 CUTTING TIME HEAD 2
438 CUTTING TIME HEAD 3
THIS 2016 NZX 2000/800STY3 HAS A CELOS (F31iB) CONTROL, TWIN SPINDLES, (3) TURRETS WITH Y-AXIS, 2 - 10" CHUCKS, 2 MICRO CENTRIC MBS COLLET CHUCKS, CHIP BLASTER HIGH PRESSURE COOLANT SYSTEM, C-AXIS HIGH PRECISION INDEXING, HOBBIN & MORE.
Imperial
| Maximum Swing | 31.5" |
| Max Turning Diameter | 31.8" |
| Main Spindle Bore/Max Bar Capacity | 2.9"/ 2.6" |
| Tail Stock/Sub Spindle | Sub Spindle |
| X-Axis Travel (X1, X2, X3) | 8.3" |
| Z-Axis Travel (Z1, Z2, Z3) | 11.8"/31.9"/11.8" |
| Y-Axis Travel (Y1, Y2, Y3) | 4.3" |
| C-Axis Indexing (1, 2) | C-Axis High-Precision Indexing |
| Main Spindle Chuck Size | 10" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 2.9" |
| Main Spindle Maximum Bar Work | 2.6" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 33.3/30 |
| Sub Spindle/2nd Spindle Chuck Size | 10 |
| Sub Spindle/2nd Spindle Bore Size | 2.9 |
| Sub Spindle/2nd Spindle Chuck Type | Hydraulic |
| Sub Spindle/2nd Spindle Speed | 5,000 RPM |
| Sub Spindle/2nd Spindle Horsepower (CONT. /30 MINS) | 33.3/30 |
| Number of Turrets | 2 |
| Turret Tool Positions 1, 2 | 16 |
| Turret Type | 16 X 3 TURRETS |
| Turret Rotary Tool Spindle Speed 1, 2 | 12000 |
| Turret Rotary Tool Horse Power 1, 2 | 7.5 |
| Chip Conveyor | Yes |
| Tool Eye Automatic Front Spindle | Yes |
| Tool Eye Automatic Second Spindle | Yes |
| High Pressure Coolant System (PSI) | 1000 |
| Hobbing Function | YES |
| Upper Turret Positions | 16 |
| Lower Turret Positions | 16 |
| Y-Axis | Upper Turret |
| Y-Axis | Upper and Lower Turrets |
| Control | CNC (CELOS (F31IB)) |
| Dimensions | 199.3" X 111.6" X 91.3" |
| Weight | 21,120 LBS |
CELOS (F31IB) CNC CONTROL
21.5" COLOR ERGOLINE TOUCH TFT
TWIN SPINDLES
(3) TURRETS WITH Y-AXIS
12,000 RPM MILLING SPEED
(2) MICRO CENTRIC MBS 200 COLLET CHUCKS
CHIP BLASTER/CHIP CHILLER HIGH PRESSURE COOLANT SYSTEM
COOLANT GUN
CHUCK TOP COOLANT
AIR PURGE (LEFT AND RIGHT SPINDLE)
AIR BLOW FOR TOOL TIP (T1, T2, AND T3)
X-AXIS DIRECT SCALE FEEDBACK (X1, X2, X3)
CHIP CONVEYOR (SIDE EXIT SCRAPER TYPE)
ETHERNET CAPABILITY
AUTOMATIC DOOR
TOOL PRESETTER (LEFT AND RIGHT SPINDLE)
(5) EXTERNAL M-CODES
3-D COORDINATE CONVERSION
TOOL RETRACT AND RECOVER
HOBBING FUNCTION
X-AXIS DIRECTION JIS / ISO
C-AXIS HIGH-PRECISION INDEXING
4 COLOR SIGNAL LIGHT
BUILT IN WORK LIGHT
17,110 POWER ON TIME
663 OPERATION TIME HEAD 1
1907 OPERATION TIME HEAD 2
1662 OPERATION TIME HEAD 3
609 CUTTING TIME HEAD 1
375 CUTTING TIME HEAD 2
438 CUTTING TIME HEAD 3
