NAKAMURA-TOME SUPER WT-150IIMMY, CNC TURNING CENTER LATHE, LOW HOURS, 2016
Have one to sell?
ConditionUsed
1 available
THIS 2016 NAKAMURA TOME SUPER WT-150IIMMY HAS A BARFEEDER, PARTS CATCHER, CHIP CONVEYOR, HIGH-PRESSURE COOLANT, AND PARTS CONVEYOR. THIS IS A LOW-HOUR, ONE-SHIFT MACHINE THAT IS MACHINED MOSTLY 3/16” STAINLESS
MAX. TURNING DIAMETER 7.5”
STANDARD TURNING DIAMETER 6.7”
DISTANCE BETWEEN CENTERS MAX. 29.6”, MIN. 7.9”
MAX. TURNING LENGTH 20.3”
BAR CAPACITY 2”
AXIS TRAVEL
SLIDE TRAVEL X1 / X2 6.6”
SLIDE TRAVEL Z1 / Z2 20.3”
SLIDE TRAVEL Y +/-1.4”
SLIDE TRAVEL (B-AXIS) 23.7”
RAPID FEED X1 / X2 630 IPM
RAPID FEED Z1 / Z2 1575 IPM
RAPID FEED (B-AXIS) 1575 IPM
RAPID FEED Y 236 IPM
LEFT AND RIGHT SPINDLES
SPINDLE SPEED 5000 RPM
SPINDLE SPEED RANGE STEPLESS
SPINDLE NOSE A2-5
HOLE THROUGH SPINDLE 2.5”
HOLE THROUGH DRAW TUBE 2”
C-AXIS
LEAST INPUT INCREMENT DEGREES 0.001
LEAST COMMAND INCREMENT DEGREES ARE 0.001
RAPID INDEX SPEED 600 RPM
CUTTING FEED RATE 1~4800 DEG/MIN
C-AXIS CLAMP DISK CLAMP
UPPER AND LOWER TURRETS
TYPE OF TURRET HEAD DODECAGONAL DRUM TURRET
NUMBER OF TOOL STATIONS 24
NUMBER OF INDEXED POSITIONS 48
TOOL SIZE SQUARE / ROUND 1” / 1.3”
ROTATING TOOL
ROTARY SYSTEM INDIVIDUAL ROTATION
SPINDLE SPEED RPM 6000 RPM
DRIVE MOTOR
LEFT SPINDLE 20 / 15 HP
RIGHT SPINDLE 15 / 10 HP
DRIVEN TOOLS 7.5 HP
NOTE: CUTTING TOOLS INSIDE THE HOLDERS ARE NOT INCLUDED - THANK YOU
NT SMARTX CONTROL
2 TURRETS
Y-AXIS ( UPPER TURRET)
MILLING ( LOWER TURRET)
2 S-20 COLLET CHUCKS
1 KITAGAWA B-206 3 JAW CHUCK
C-AXIS
HIGH-PRESSURE COOLANT
REMOVABLE TOOL SETTER
LNS CHIP CONVEYOR
PARTS CATCHER G
PARTS CONVEYOR
LNS QUICK LOAD SERVO S3-T BAR FEED
SPINDLE LINERS
(1) KZ1510 CROSS MILL/DRILL ER25, 16912076
(1) KZ1510C CROSS MILL/DRILL ER25, COOLANT THRU
(1) KZ1510S CROSS MILL/DRILL, 2:1 SPEEDER, ER20, MA2.5S RT 2:1 16912031
(3) KZ1513 FACE MILL/DRILL ER25
THIS IS A LOW-HOUR, ONE-SHIFT MACHINE THAT IS MACHINED MOSTLY 3/16” STAINLESS
**220 VOLT 3 PHASE 60 CYCLE **
THIS 2016 NAKAMURA TOME SUPER WT-150IIMMY HAS A BARFEEDER, PARTS CATCHER, CHIP CONVEYOR, HIGH-PRESSURE COOLANT, AND PARTS CONVEYOR. THIS IS A LOW-HOUR, ONE-SHIFT MACHINE THAT IS MACHINED MOSTLY 3/16” STAINLESS
Imperial
| Max Turning Diameter | 7.5" |
| Main Spindle Bore/Max Bar Capacity | 2.4"/ 2.0" |
| Tail Stock/Sub Spindle | Tail Stock |
| Distance Between Centers | 29.6" |
| Maximum Cutting Length | 20.3" |
| X-Axis Travel (X1, X2, X3) | 6.6" |
| Z-Axis Travel (Z1, Z2, Z3) | 20.3" |
| Y-Axis Travel (Y1, Y2, Y3) | +/- 1.4" |
| C-Axis Indexing (1, 2) | 0.001 |
| Main Spindle Chuck Size | 8" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 2.5" |
| Main Spindle Maximum Bar Work | 2" |
| Main Spindle Speed | 5,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 20/ 15 |
| Number of Turrets | 2 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Type | DODECAGONAL DRUM TURRET |
| Turret Rotary Tool Spindle Speed 1, 2 | 6000 |
| Turret Rotary Tool Horse Power 1, 2 | 7.0 |
| B-Axis Travel | 23.7" |
| Rapid Traverse, X-Axis | 0 |
| Rapid Traverse, Y-Axis | 236 |
| Rapid Traverse, Z-Axis | 0 |
| Control | CNC (NT SMARTX) |
| Dimensions | (L X W X H) 142 X 78 X 73 |
| Weight | 19,621 LBS |
MAX. TURNING DIAMETER 7.5”
STANDARD TURNING DIAMETER 6.7”
DISTANCE BETWEEN CENTERS MAX. 29.6”, MIN. 7.9”
MAX. TURNING LENGTH 20.3”
BAR CAPACITY 2”
AXIS TRAVEL
SLIDE TRAVEL X1 / X2 6.6”
SLIDE TRAVEL Z1 / Z2 20.3”
SLIDE TRAVEL Y +/-1.4”
SLIDE TRAVEL (B-AXIS) 23.7”
RAPID FEED X1 / X2 630 IPM
RAPID FEED Z1 / Z2 1575 IPM
RAPID FEED (B-AXIS) 1575 IPM
RAPID FEED Y 236 IPM
LEFT AND RIGHT SPINDLES
SPINDLE SPEED 5000 RPM
SPINDLE SPEED RANGE STEPLESS
SPINDLE NOSE A2-5
HOLE THROUGH SPINDLE 2.5”
HOLE THROUGH DRAW TUBE 2”
C-AXIS
LEAST INPUT INCREMENT DEGREES 0.001
LEAST COMMAND INCREMENT DEGREES ARE 0.001
RAPID INDEX SPEED 600 RPM
CUTTING FEED RATE 1~4800 DEG/MIN
C-AXIS CLAMP DISK CLAMP
UPPER AND LOWER TURRETS
TYPE OF TURRET HEAD DODECAGONAL DRUM TURRET
NUMBER OF TOOL STATIONS 24
NUMBER OF INDEXED POSITIONS 48
TOOL SIZE SQUARE / ROUND 1” / 1.3”
ROTATING TOOL
ROTARY SYSTEM INDIVIDUAL ROTATION
SPINDLE SPEED RPM 6000 RPM
DRIVE MOTOR
LEFT SPINDLE 20 / 15 HP
RIGHT SPINDLE 15 / 10 HP
DRIVEN TOOLS 7.5 HP
NOTE: CUTTING TOOLS INSIDE THE HOLDERS ARE NOT INCLUDED - THANK YOU
NT SMARTX CONTROL
2 TURRETS
Y-AXIS ( UPPER TURRET)
MILLING ( LOWER TURRET)
2 S-20 COLLET CHUCKS
1 KITAGAWA B-206 3 JAW CHUCK
C-AXIS
HIGH-PRESSURE COOLANT
REMOVABLE TOOL SETTER
LNS CHIP CONVEYOR
PARTS CATCHER G
PARTS CONVEYOR
LNS QUICK LOAD SERVO S3-T BAR FEED
SPINDLE LINERS
(1) KZ1510 CROSS MILL/DRILL ER25, 16912076
(1) KZ1510C CROSS MILL/DRILL ER25, COOLANT THRU
(1) KZ1510S CROSS MILL/DRILL, 2:1 SPEEDER, ER20, MA2.5S RT 2:1 16912031
(3) KZ1513 FACE MILL/DRILL ER25
THIS IS A LOW-HOUR, ONE-SHIFT MACHINE THAT IS MACHINED MOSTLY 3/16” STAINLESS
**220 VOLT 3 PHASE 60 CYCLE **
