MAZAK NEXUS QTN 450MII/1000
Have one to sell?
ConditionUsed
1 available
MAZATROL MATRIX CNC CONTROL
AUTOMATIC TOOL SETTER
COMPARISON STOP, G54.1, SYNC. MILL TAPPING
SAMCHULLY MH-18 HYDRAULIC CHUCK - NEW
REAR CHUCK PREP
SPIRAL,
RETHREADING
EIA 3D COMP, ROTATION,
GEOMETRIC, SCALING,
THREAD, INVERSE TIME,
AUTO ATLM,
POLAR COORDINATE INPUT
TILTED WORK PLANE,
PITCH ERROR COMP
VARIABLE 600 SETS,
EIA HELICAL TAP,
PATTERN CYCLE
CHIP CONVEYOR
EXT-DATA I/O
Imperial
| Maximum Swing | 33.26" |
| Max Turning Diameter | 22.83" |
| Main Spindle Bore/Max Bar Capacity | 7.12"/ 6.49" |
| Tail Stock/Sub Spindle | Tail Stock |
| Distance Between Centers | 42" |
| Maximum Cutting Length | 40.2" |
| X-Axis Travel (X1, X2, X3) | 12.21 |
| Z-Axis Travel (Z1, Z2, Z3) | 40.12 |
| C-Axis Indexing (1, 2) | .001 Degrees |
| Main Spindle Chuck Size | 18" |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 6.5" |
| Main Spindle Maximum Bar Work | 6.49" |
| Main Spindle Speed | 2,000 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 40 |
| Rear Chuck Prep | Yes |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 2000 |
| Turret Rotary Tool Horse Power 1, 2 | 10 |
| Chip Conveyor | Yes |
| Control | CNC (MAZATROL MATRIX) |
| Weight | 26,800 LBS. |
MAZATROL MATRIX CNC CONTROL
AUTOMATIC TOOL SETTER
COMPARISON STOP, G54.1, SYNC. MILL TAPPING
SAMCHULLY MH-18 HYDRAULIC CHUCK - NEW
REAR CHUCK PREP
SPIRAL,
RETHREADING
EIA 3D COMP, ROTATION,
GEOMETRIC, SCALING,
THREAD, INVERSE TIME,
AUTO ATLM,
POLAR COORDINATE INPUT
TILTED WORK PLANE,
PITCH ERROR COMP
VARIABLE 600 SETS,
EIA HELICAL TAP,
PATTERN CYCLE
CHIP CONVEYOR
EXT-DATA I/O
