MAZAK CYBERTECH TURN 4500M/ 3000
CNC LATHES MULTI AXIS
THIS CYBERTECH 4500M HAS 120" CENTERS, FUSION 640MT CONTROL, HYDRAULIC CHUCK WITH 6.5" BAR CAPACITY, HYDRAULIC STEADY REST AND SOME LIVE TOOLING..
| Maximum Swing | 33.88" |
| Max Turning Diameter | 31.88" |
| Main Spindle Bore/Max Bar Capacity | 7.2"/ 6.5" |
| Tail Stock/Sub Spindle | Tail Stock MT #5 |
| Maximum Swing Over Cross Slide | 27.5" |
| Maximum Cutting Length | 120" |
| X-Axis Travel (X1, X2, X3) | 21.26" |
| Z-Axis Travel (Z1, Z2, Z3) | 123.25" |
| C-Axis Indexing (1, 2) | .001 Deg |
| Main Spindle Chuck Type | Hydraulic |
| Main Spindle Bore Diameter | 7.2" |
| Main Spindle Maximum Bar Work | 6.5" |
| Main Spindle Speed | 600 RPM |
| Main Spindle Horsepower (CONT. /30 MINS) | 50 |
| Rear Chuck | No |
| Number of Turrets | 1 |
| Turret Tool Positions 1, 2 | 12 |
| Turret Rotary Tool Spindle Speed 1, 2 | 3000 |
| Turret Rotary Tool Horse Power 1, 2 | 15 |
| Chip Conveyor | Side |
| Tool Eye Automatic Front Spindle | Yes |
| Coolant Thru Milling Head | No |
| Multi Tap Transformer | Yes |
| Rapid Traverse, X-Axis | 945 |
| Rapid Traverse, Z-Axis | 1181 |
| Control | CNC (MAZATROL FUSION 640 MT PRO) |
| Dimensions | 284" X 98" X 111" |
| Weight | 40,000 LBS. |
MAZATROL FUSION 640MT PRO
HYDRAULIC CHUCK
HYDRAULIC STEADY REST -
LIVE TOOLING
